REFRIGERATION
HINGES
PERFORMER LIFT-OFF ADJUSTABLE HINGES
by KASON ® PERFORMER LIFT-OFF ADJUSTABLE HINGES
by KASON ®
• Commonly used on American-Kooler, American Panel, Kolpak,
International Cold Storage, and Thermo-Kool ®
• Left- and right-hand
• Strap adjusts horizontally to provide door lift and rotation
for sagging in door frame or mounting
• Chrome with black diamond cover
• Kason no. 1346 • Commonly used on Kolpak ®
• Flush
• Strap adjusts horizontally to provide door lift and rotation
for sagging in door frame or mounting
• Includes gray plastic cover
• Kason no. 1345
No.
No.
No.
No.
123-1290
123-1291
123-1292
123-1293
Flush mount
1 1 ⁄ 8 " (28mm) offset
1 1 ⁄ 4 " (31mm) offset
1 3 ⁄ 8 " (35mm) offset
8"
No. 123-1288 Left-hand
No. 123-1286 Right-hand
Replacement Parts
No. 123-1289 Cam and follower kit
9"
(203mm)
3"
6"
(76mm)
(152mm)
(229mm)
1 5 ⁄ 8 "
8 1 ⁄ 4 "
(41mm)
(209mm)
For important information on how to measure offsets, see the front of the Refrigeration section.
Cam Lift Hinges
• Chrome-plated
• Standard Keil nos. 2860, 9300L
• CHG no. W60
Cam Lift Hinges Spring Cartridge Kit
• Chrome-plated
• Kason no. 1245 No. 123-1144
• Converts the following hinges to spring-assisted:
123-1146, 123-1147, 123-1148, 123-1149,
123-1150, 123-1151, 123-1152
• Gives extra closing power
• Kit includes installation instructions
• CHG no. W62-0001
• Standard Keil no. 2862
No. 123-1160 Flush
No. 123-1158 1 1 ⁄ 8 " (29mm) offset
No. 123-1159 1 3 ⁄ 8 " (35mm) offset
Replacement Parts
No. 123-1153 Male cam
10"
2 7 ⁄ 8 "
(73mm)
5 1 ⁄ 2 "
123-1152 Flush
123-1148 1 1 ⁄ 8 " (29mm) offset
123-1147 1 1 ⁄ 4 " (32mm) offset
123-1150 1 3 ⁄ 8 " (35mm) offset
123-1146 1 1 ⁄ 2 " (38mm) offset
123-1149 1 3 ⁄ 4 " (44mm) offset
123-1151 2" (51mm) offset
Replacement Parts
No. 123-1136 Cam set (not shown)
• Includes male and female cams
• CHG no. W60Y015
10" (254mm)
(254mm)
(140mm)
254
No.
No.
No.
No.
No.
No.
No.
2 7 ⁄ 8 "
(73mm)
fmponline.com
5 1 ⁄ 2 "
(140mm)
