REFRIGERATION
REVERSIBLE SPRING-ASSISTED
HINGE FOR BALLY
No. 123-1240
• Flush mount
• Satin aluminum
• Replaces Dent no. D125
• Bally nos. 230, D1250
7 ⁄ 4 "
1
CAM LIFT HINGE CAM LIFT HINGES
No. 123-1239
• Commonly used on Kolpak ® and Vollrath ®
• Flush mount
• Satin chrome-plated
• CHG no. W56-1000 • Flush mount
• Can be used on left- or right-hand doors
• Satin chrome-plated
(184mm)
No. 123-1254 Upper
• Kolpak no. 236211075
No. 123-1253 Lower
• Kolpak no. 236201075
8" (203mm)
8 1 ⁄ 4 "
7"
6 15 ⁄ 16 "
3"
(210mm)
(176mm)
(76mm)
HINGES
3"
(76mm)
(178mm)
7"
3"
(178mm)
(76mm)
Hinges are reversible for left- or right-hand doors, unless otherwise specified.
Cam Lift Hinge
No. 123-1022
• Commonly used on Kolpak ® and Vollrath ®
• Flush mount
• Satin chrome-plated
• Kason nos. 1256, 11256000004
• Kolpak no. 236001075
Cam Lift Hinge
No. 123-1021
• Commonly used on Kolpak ® and Vollrath ®
• Flush mount
• Satin chrome-plated
• Kason no. 1255
Replacement parts
No. 123-1274 Cam
• Kason no. 91245004520117R
6"
7"
(178mm)
(152mm)
Spring Cartridge Kit Replacement parts
No. 123-1026
• Converts cam lift hinge (Nos. 123-1021 and
123-1022) to spring-assisted
• Gives extra closing power
• Kit includes installation instructions No. 123-1251 Cam set (not shown)
• Includes male and female cam, and pin
• Kolpak no. 106221080
No. 123-1274 Cam
• Kason no. 91245004520117R
Replacement parts
No. 123-1273 Male cam
• Kit includes threaded rod
• Kason no.
