REFRIGERATION
Door Pull Door Pulls Door Pull Door Pull
No. 124-1155
• 14 5 ⁄ 8 " overall length
• Screw centers:
13 7 ⁄ 16 " front mount,
12 7 ⁄ 16 " rear mount
• Screw holes:
3
⁄ 16 " unthreaded front mount,
1
⁄ 4 -20 thread rear mount
• Chrome-plated • 1 ⁄ 4 -20 thread
• Front or rear mount
• Aluminum with plastic
supports and insert No. 124-1156
• 12 13 ⁄ 16 " overall length
• Screw centers:
11 5 ⁄ 8 " front mount,
10 5 ⁄ 8 " rear mount
• Screw holes:
3
⁄ 16 " unthreaded front mount,
1
⁄ 4 -20 thread rear mount
• Chrome-plated No. 124-1151
• 12 5 ⁄ 8 " overall length
• 11" screw centers
• 1 ⁄ 4 -20 thread
• Rear mount
• Polished aluminum
No. 124-1281
• 7 3 ⁄ 4 " (197mm) overall length
• 6" (152mm) screw centers
No. 124-1150
• 12 1 ⁄ 4 " (311mm) overall length
• 10 5 ⁄ 8 " (270mm) screw centers
Door Pull
No. 238-1003
• 7 1 ⁄ 8 " (181mm) overall length
• 1" (25mm) wide
• 5 1 ⁄ 2 " (140mm) screw centers
• Front mount
• Bally no. 16556
Door Pull Door PULL
No. 124-1148
• Offset handle
• 5 7 ⁄ 8 " overall length
• 5" screw centers
• 1 ⁄ 4 -20 female thread
• Rear mount
• Chrome-plated No. 269-1070
• 6 1 ⁄ 2 " (165mm) overall length
• 6 1 ⁄ 4 " (159mm) screw centers
• Black textured metal grip
with chrome-plated mounts
RECESSED PULL
No. 124-1354
• Fits 1 3 ⁄ 16 " x 5 3 ⁄ 16 " (30mm x 132mm)
rectangular opening
• 5 7 ⁄ 16 " (138mm) overall length
• 1 7 ⁄ 16 " (37mm) overall width
• Black thermoplastic
HINGES
Edgemount Hinges
1"
Edgemount hinge offsets in this catalog
are measured from the base of the hinge
(where it attaches to the cabinet) to the
center of the screw holes where the hinge
attaches to the door.
See illustration at the beginning of the
Refrigeration section.
Since some hardware manufacturers
measure their offsets differently, the offset
stamped on the hinge may differ from the
offset shown in this catalog.
Hinges can be used on either
right- or left-hand doors, unless otherwise
specified. See the beginning of the
Refrigeration section for how to
determine whether a door is
right- or left-handed.
(25mm)
2
Frame
Door
1 3 ⁄ 16 "
(30mm) 1 3 ⁄ 16 "
(30mm)
1 3 ⁄ 16 " 1 3 ⁄ 16 "
(30mm)
1
(30mm)
5 3 ⁄ 4 "
(146mm)
Hinges
• Offset is adjustable
• Chrome-plated
• Kason no. 217
3
⁄ 16 " (5mm)
1. No. 123-1055 1 ⁄ 2 " (13mm) offset
1. No. 123-1053 3 ⁄ 4 " (19mm) offset
1. No. 123-1054 1" (25mm) offset
Replacement Parts
2. No. 123-1052 Cover
Note: Offsets shown here may differ
from what is stamped on hinge.
Hinges pictured on this page include the hinge cover.
For the “Refrigeration Hardware Locator,” see the front of the Refrigeration section.
Phone: 800-257-7737
24-Hour Fax: 800-255-9866
245
Door Pulls
