FMP-COMERSAMX CATALOGO FMP | Page 304

REFRIGERATION
HINGES
3
⁄ 4 "
(19mm)
11
⁄ 16 "
(17mm)
Door
Frame
1 7 ⁄ 8 "
(48mm)
1 7 ⁄ 8 "
(48mm)
1
2
Door
Frame
4 1 ⁄ 2 "
(114mm)
13
⁄ 16 "
(21mm)
7
⁄ 8 "
(22mm)
5"
(127mm)
13
⁄ 16 "
(21mm)
7
⁄ 8 "
(22mm)
Hinge
Hinges
• Offset is adjustable
• Chrome-plated
• Kason no. 212
No. 123-1047
• 1" (25mm) offset
• Offset is adjustable 3 ⁄ 16 " (5mm)
• Chrome-plated
• Replaces National Lock nos. 59-8426,
59-8438-A
• Replaces Standard Keil nos. 2840,
7820
• CHG no. R40
3
⁄ 16 " (5mm)
1. No. 123-1043 1 ⁄ 2 " (13mm) offset
1. No. 123-1041 3 ⁄ 4 " (19mm) offset
1. No. 123-1042 1" (25mm) offset
Replacement Parts
2. No. 123-1040 Cover
Edgemount Hinges
Edgemount hinge offsets in this catalog are measured from the base of the hinge (where it attaches to the c
