REFRIGERATION
Safety Lever handles
Unilatch Locking Door Pull
LATCH WITH LOCK AND Inside RELEASE
Unique locking pull needs no strike because it works through the
door. Combination lock and safety release is located on the back
of the door inside the walk-in.
No. 122-1225
• Inside release for doors up to 4"
• Satin aluminum
• Dent no. D89FNS
(102mm)
No. 122-1251
• Includes handle, cylinder lock with 2 keys (No. 122-1252),
glow-in-the-dark plate, sticker, inside release (No. 122-1253),
and freezer kit
• Satin aluminum
• Kolpak no. 236091075
thick
Replacement Parts
No. 122-1253 Inside release
No. 124-1359 Keys
• Sold by the pair
No. 122-1252 Cylinder lock kit
• Kit includes: 2 keys, cylinder lock, and hardware
2 1 ⁄ 4 "
(57mm)
13 3 ⁄ 4 "
(349mm)
2 1 ⁄ 8 "
(54mm)
15 7 ⁄ 8 "
(403mm)
Locking Devices
Padlock Hasp with
Inside Release
No. 124-1138
• Permits escape when door is locked
• 1 1 ⁄ 4 " (32mm) offset
• Inside release for walls up to 4" (102mm) thick
• Chrome-plated
Padlock Hasp with
Inside Release
No. 124-1320
• Permits escape when door is locked
• 1 3 ⁄ 8 " (35mm) offset
• Inside release for walls up to 4" (102mm) thick
• Chrome-plated
244
Heavy-Duty
Locking Bar
with Inside Release
No. 124-1147
• For doors up to 36" (914mm) wide
• Permits escape when door is locked
• For use on flush doors
• Inside release for walls up to 4" (102mm) thick
• 5 3 ⁄ 8 " (137mm) bolt length
• Distance between release and bolt
is 39 1 ⁄ 2 " to 41" (1003mm to 1041mm)
• Stainless steel locking bar with
glow-in-the-dark plastic inside release knob
fmponline.com
Long Shackle
Brass Padlocks
• Include 2 keys each
• Locks not keyed alike
No. 134-1117 1 1 ⁄ 2 " (38mm) padlock body
• 1 ⁄ 4 " (6mm) diameter shackle
• Shackle is 3" H x 25 ⁄ 32 " W
(76mm x 20mm) closed
No. 134-1054 1 3 ⁄ 4 " (45mm) padlock body
• 5 ⁄ 16 " (8mm) diameter shackle
• Shackle is 3" H x 29 ⁄ 32 " W
(76mm x 23mm) closed
