PLUMBING
Replacement Parts & Accessories for Fisher Pre-Rinses
1
2
Spout Adaptors
1. No. 113-1136 Fisher spout thread female

inlet to 3 ⁄ 8 " NPT female outlet
• Converts faucet base to pre-rinse
wall adaptor Elbow
Connects wall mount faucet or pre-rinse
to supply line.*
2. No. 113-1137 3 ⁄ 8 " NPT male inlet to Fisher

spout thread male outlet
• Converts pre-rinse base to faucet base
No. 113-1130
• Fits standard 2" backsplash
• 1 ⁄ 2 " NPT female inlet and outlet
• Stainless steel
• Fisher no. 71498
* 1 ⁄ 2 " NPT nipple kits (Nos. 117-1408 and
117-1334) may be required with most wall
mounted faucet and pre-rinse applications.
ADD-ON PRE-RINSE FAUCETS
• Can be used with most pre-rinse assemblies
• 3 ⁄ 8 " NPT male inlet x 3 ⁄ 4 " NPT female outlet
No. 112-1048 6" spout
• Stainless steel
• Fisher nos. 2901, 71323
No. 112-1047 12" spout
• Stainless steel
• Fisher nos. 2901-12, 71366
WATTS ® BACKFLOW
PREVENTER
No. 117-1409
• For use on bottom of pre-rinse
riser tubes
• 3 ⁄ 8 " NPT male inlet
• 3 ⁄ 8 " NPT female outlet
• Rated 125 PSI
• Chrome-plated brass
• CHG no. K50X139B
No. 113-1112 Replacement stem

assembly only
• Stainless steel
• Fisher no. 54518
SUPPLY LINE
No. 113-1084
• 36" long, braided stainless steel
• 1 ⁄ 2 " NPSM female x 1 ⁄ 2 " NPT
male fittings
Wall Bracket
No. 113-1029
• For 3 ⁄ 8 " NPT riser pipe
• Adjustable from 2 1 ⁄ 4 " to 12"
• Adjustment is measured from wall to
center line of riser
BACKFLOW
PREVENTER
No. 113-1129
• For use between the pre-rinse
hose and spray valve
• 2 check valves ensure safety in
case 1 fails
• 3 ⁄ 4 -14 thread female inlet
• 3 ⁄ 4 -14 thread male outlet
• Stainless steel
• Fisher no. 2932-0002
Gooseneck Swivel
No. 113-1090
• For use on swivel pre-rinses
• Can also convert a standard pre-rinse
into a swivel
• Chrome-plated brass
• Fisher no. 2011-0000
Wall Hook
No. 113-1014
• For pre-rinses and pot filler valves
• Chrome-plated brass with vinyl-coated hook
