FMP-COMERSAMX CATALOGO FMP | Page 232

PLUMBING
Replacement Parts & Accessories for T&S Brass Pre-Rinses
1
Add-On Swing Faucets
Swivels • For use with pre-rinse assemblies
• 3 ⁄ 8 " NPT male inlet and 3 ⁄ 8 " NPT female outlet
• Chrome-plated brass
1. No. 111-1219 Swivel arm assembly
• For use on pre-rinses (Nos. 110-1169 and 110-1191)
• 12" long
• T&S no. 2882-40 ITEM No.
110-1179
110-1177
110-1178
2
2. No. 111-1227 Swivel adaptor
• For use on faucet and spray assembly
(No. 110-1176)
• T&S no. 34A
SPOUT
6"
12"
18"
T&S No.
B0155M
B0156M
B0157M
Replacement Parts
• 3 ⁄ 8 " NPT male inlet and 3 ⁄ 8 " NPT female outlet
• Spout not included
• Chrome-plated brass
No. 111-1315 Add-on faucet body
• T&S no. B0155LN
No. 110-1246 EasyInstall ® add-on faucet body
• T&S no. B0155LNEZ
No. 111-1220 Stem assembly
• T&S no. 2713-40
No. 111-1175 EasyInstall ® adaptor
WALL HOOK
No. 111-1307
• For pre-rinse and pot hooks
• 2" (51mm) flange
• T&S no. B0166
Elbow
Connects wall mount faucet or pre-rinse
to supply line.
No. 111-1241
• Fits standard 2" backsplash
• 1 ⁄ 2 " NPT female inlet and outlet
• Brass
• T&S no. 6895-20
174
Pre-Rinse
Wall Brackets
• Length shown above is the distance from
the wall to the center line of the riser tube
• Can be cut in the field
• For 3 ⁄ 8 " NPT riser pipe
• T&S no. B109 series
No. 111-1017 Adjusts from 2" to 6 ⁄ 4 " long
• T&S no. B0109-03
No. 111-1018 Adjusts from 2" to 12 3 ⁄ 4 " long
• T&S no. B0109-01M
No. 111-1019 Adjusts from 2" to 18 3 ⁄ 4 " long
• T&S no. B0109-04
3
fmponline.com
Pot Filler
No. 111-1222
• Fits T&S Brass pre-rinse hose
• T&S no. 2851-40 (old no. 26A)
