PLUMBING
GRATEs for Smith
Floor Drains
• Includes brass screws
• Brass
DRAIN OUTSIDE SCREW
ITEM No.
SIZE
DIA.
CTRS.
3 7 ⁄ 8 "
5"
4 5 ⁄ 8 "
102-1080
1
6"
5 ⁄ 2 "
4 15 ⁄ 16 "
102-1081
7"
6 7 ⁄ 16 "
5"
102-1082
8"
7 7 ⁄ 16 "
6 1 ⁄ 16 "
102-1083
No. 102-1106 Replacement screw
LOCK AND STOP™ FLOOR DRAIN LOCKS
Avoid costly plumbing bills by keeping your plumbing lines
free of unwanted debris!
Prevent unauthorized removal of drains. Make drains virtually
immovable—easy-to-install expandable steel cross member anchors to
drain piping while a bolt is inserted through the drain strainer and steel
cross member. The custom-made bolt head can only be removed with a
special spanner bit (included). All stainless steel construction makes
Lock and Stop™ drain locks durable, corrosion proof, and impenetrable.
• Can be used with 4" opening floor drain strainer (No. 102-1136) or
6" opening floor drain strainer (No. 102-1137)
• Includes installation tool and custom bolt spanner bit
• Stainless steel
No. 102-1177 Fits standard 2" (51mm) floor drain piping
No. 102-1178 Fits standard 3" (76mm) floor drain piping
No. 102-1181 Fits standard 4" (102mm) floor drain piping
Locking
spanner bit
Replacement Parts
No. 102-1182 Lock bolt
• Tamperproof drilled spanner head
Installation tool
Bolt and expandable
steel cross member
No. 142-1621 Locking spanner bit
FLOOR DRAIN GRATE
by ZURN ® FLOOR DRAIN GRATE
by zurn ®
No. 102-1191
• 5" (127mm) OD
• 3 7 ⁄ 8 " (98mm) screw centers
• Bronze
• Zurn no. PN400-5BSTR No. 102-1169
• For 5" x 5" (127mm x 127mm) floor drains
• 4 5 ⁄ 8 " (118mm) square
• 3 7 ⁄ 8 " (98mm) screw centers
• Nickel-bronze
• Zurn no. PN400-5S-GRID
Phone: [phone]
24-Hour Fax: [phone]
107
