PLUMBING
Floor drain strainers
P ERMA D RAIN ® FLOOR DRAIN DOME STRAINERS
Save time, money, and your drains.
Protect drains by helping to reduce blockages and lessen damage to cables.
Provide a more sanitary environment by reducing backups and decrease business
downtime caused by clogs.
• Fits floor sinks, floor drains, mop sinks, and other drains
• 5 1 ⁄ 2 " OD x 3" H (140mm x 76mm) dome
• Used under floor drain safety baskets (Nos. 102-1198, 102-1199, 102-1200,
102-1201, 102-1202, and 102-1203)
• Includes 2 gaskets to ensure proper drain pipe fitting, self-tapping 6" screw,
and square bit for installation
• Blue plastic
No. 102-1196 Fits 3" (76mm) drains
No. 102-1197 Fits 4" (102mm) drains
P ERMA D RAIN ® FLOOR DRAIN SAFETY BASKETS
• Can be used with PermaDrain ® floor drain dome strainers
(Nos. 102-1196 and 102-1197)
• Removable for cleaning
• Yellow heavy-duty plastic
No. 102-1198 Fits 6" to 6 1 ⁄ 2 " (152mm to 165mm) square floor sink
• 6" x 6" x 1 3 ⁄ 4 " H (152mm x 152mm x 44mm) overall dimensions
No. 102-1199 Fits 8" (203mm) cast iron floor sinks
• 6 1 ⁄ 2 " x 6 1 ⁄ 2 " x 1 3 ⁄ 4 " H (165mm x 165mm x 44mm) overall dimensions
No. 102-1200 Fits 8" to 8 1 ⁄ 2 " (203mm to 216mm) square floor sink
• 8" x 8" x 2 1 ⁄ 2 " H (203mm x 203mm x 64mm) overall dimensions
No. 102-1201 Fits most 12" (305mm) cast iron floor sinks
• 8 1 ⁄ 2 " x 8 1 ⁄ 2 " x 2 1 ⁄ 2 " H (216mm x 216mm x 64mm) overall dimensions
No. 102-1202 Fits most 12" (305mm) PVC floor sinks and other applications
with 9" (229mm) ID
• 9" x 9" x 2 1 ⁄ 2 " H (229mm x 229mm x 64mm) overall dimensions
No. 102-1203 Fits most 12" (305mm) floor sinks
• For hard-to-reach areas
• 10 3 ⁄ 4 " x 10 3 ⁄ 4 " x 2 1 ⁄ 2 " H (273mm x 273mm x 64mm) overall dimensions
Dome Dish Floor Drain Strainers
• Tapered at the bottom to drop into standard floor sinks
• Dome shape keeps drain flowing evenly when strainer is partially full
• 2" (51mm) deep
• Large holes for fast draining
• Heavy-duty plastic
1
2
3
108
1. No.
1. No.
1. No.
1. No.
1. No.
2. No.
2. No.
3. No.
102-1140 6" (152mm) square
102-1141 6 1 ⁄ 2 " (165mm) square
102-1142 7" (178mm) square
102-1143 8" (203mm) square
102-1144 8 1 ⁄ 2 " (216mm) square
102-1145 6 1 ⁄ 2 " (165mm) round
102-1146 8 1 ⁄ 2 " (216mm) round
102-1147 9 3 ⁄ 4 " (248mm) round
