PLUMBING
HINGED floor drain GRATES
by fMP
Eliminate the cost and danger associated
with loose or missing floor drain grates.
FRANKLIN HINGED FLOOR DRAIN GRATEs™
for Smith Floor Drains
Unique hinged design allows for easy access drain cleaning.
Tamperproof screws prevent grates from being removed and misplaced.
Round Drains
• Reinforced 5 ⁄ 32 " nickel-bronze for added strength and durability
• Includes 1 tamperproof screw and 1 Phillips head screw
ITEM
No.
102-1152
102-1153
DRAIN
SIZE
5"
6"
OUTSIDE
DIA.
4 5 ⁄ 8 "
5 3 ⁄ 8 "
SCREW
CTRS.
4"
4 11 ⁄ 32 "
Replacement Parts
• 10-24 thread
• Pack of 25
No. 623-1014 Phillips head screws
No. 623-1015 T-20 tamperproof screws
Square Drain
No. 102-1135
• 7 3 ⁄ 8 " square
• Reinforced 1 ⁄ 4 " nickel-bronze for added strength and durability
• Includes 2 tamperproof screws and 2 Phillips head screws
Accessories and Replacement Parts
No. 142-1522 Tamperproof Torx ® screwdriver
• Fits size T-20 screws with tamperproof heads
• Non-removable tip
No. 623-1015 T-20 tamperproof screws
• 10-24 thread
• Pack of 25
No. 623-1014 Phillips head screws
• 10-24 thread
• Pack of 25
Franklin Drain Funnel
™
™
The Franklin Drain Funnel™
FUNNEL ASSEMBLY
Indirect waste draining just got easier!
Attach this unique drain funnel to any type of floor drain grate for indirect
draining of up to three 1 1 ⁄ 2 " drain pipes. Connects to any drain to contain
condensate waste from multiple sources. Its easy-off/easy-on collar feature
makes equipment movement and drain cleaning a breeze.
No. 102-1164
• Great for drainage waste from display cases, food preparation sinks, ice
bins, ice machines, refrigeration units, soda machines, steam-jacketed kettles,
steam tables, utensil washing sinks, and other similar equipment
• For floor drain grates 4" or larger
• Includes mounting hardware
• Brass
