PLUMBING
™
Keep damaging debris out of plumbing lines!
Tamperproof locking mechanism secures grates and strainers from unauthorized
removal. Reduce solid waste from entering drains. Prevent clogs, floating rags or
bags that block the pipe exit, blocking in common area or city main lines, and
cabling that damages P-traps.
• Expanding gasket collar fits snugly to drain
• Black plastic body
1
GUARDIAN™ DRAIN-LOCKS
ROUND Stainless steel Strainer
For use in floor sinks only.
1. No. 102-1165 Fits 2" (51mm) ID standard floor drain
• 2 3 ⁄ 8 " (60mm) OD top plate
• Can be installed or removed using #40 Torx ® screwdriver (No. 142-1604)
1. No. 102-1166 Fits 3" (76mm) ID standard floor drain
• 3 3 ⁄ 8 " (86mm) OD top plate
• Can be installed or removed using #45 Torx ® screwdriver (No. 142-1605)
2
1. No. 102-1167 Fits 4" (102mm) ID standard floor drain
• 4 3 ⁄ 8 " (111mm) OD top plate
• Can be installed or removed using #45 Torx ® screwdriver (No. 142-1605)
ROUND NICKEL-PLATED BRONZE Grate
For use on floor drains only.
• Can be installed or removed using #45 Torx ® screwdriver (No. 142-1605)
2. No. 102-1171 Fits 3 1 ⁄ 2 " (89mm) ID Smith™ floor drain housing
• 4 3 ⁄ 4 " (121mm) OD top plate
3
2. No. 102-1172 Fits 3 1 ⁄ 2 " (89mm) ID Josam ® floor drain housing
• 4 11 ⁄ 16 " (119mm) OD top plate
2. No. 102-1173 Fits 3 1 ⁄ 2 "
• 5" (127mm) OD top plate
2 1 ⁄ 8 "
1 7 ⁄ 8 "
(54mm)
(48mm)
(89mm)
ID Zurn ® floor drain housing
SQUARE NICKEL-PLATED BRONZE Grate
For use on floor drains only.
• Can be installed or removed using #45 Torx ® screwdriver (No. 142-1605)
3. No. 102-1174 Fits 3 1 ⁄ 2 " (89mm) wide Smith™ floor drain housing
• 4 9 ⁄ 16 " (116mm) square top plate
3 1 ⁄ 2 "
(89mm)
3. No. 102-1175 Fits 3 1 ⁄ 2 " (89mm) wide Josam ® floor drain housing
• 4 1 ⁄ 2 " (115mm) square top plate
3. No. 102-1176 Fits 3 1 ⁄ 2 " (89mm) wide Zurn ® floor drain housing
• 4 11 ⁄ 16 " (119mm) square top plate
GUARDIAN™ DOME LOCKS
Dome shape allows water to flow even with debris build-up in the sink.
• Aluminum dome
4. No. 102-1204 Fits 2" (51mm) wide floor drain
• Can be installed or removed using #40 Torx ® screwdriver (No. 142-1604)
4. No. 102-1205 Fits 3" (76mm) wide floor drain
• Can be installed or removed using #45 Torx ® screwdriver (No. 142-1605)
4. No. 102-1206 Fits 4" (102mm) wide floor drain
• Can be installed or removed using #45 Torx ® screwdriver (No. 142-1605)
TORX ® TAMPERPROOF SCREWDRIVERS
• Non-removable tip
4
No. 142-1604 #40
No. 142-1605 #45
