E CO F L E X
pipe freeze protection cable
Ecoflex PFP cable is a simple solution to prevent
frozen pipes in domestic and small commercial
buildings. Composed of a pre-terminated fixed
resistance heating cable fitted with a pipe thermostat
this really is a simple, low cost solution.
The integrated thermostat monitors pipe temperature
and energises the system when there is a risk of
freezing. Once a safe pipe temperature has been
reached the cable is de-energised to save energy.
Available in a range of 9 sizes, the product is fitted with a
1.5m cold lead and 3 pin plug for easy connection to the
power supply. The product can simply be installed in a
straight line along pipes up to 50mm diameter.
Additional accessories required for installation are PFP
fixing tape to secure the cable to the pipe and Alu50
aluminium heat dispersion tape for installation onto
plastic pipework. Once the cable has been installed
the entire installation should be covered with a layer of
20mm ( max ) thick flame retardant insulation.
Installation
Wrap plastic pipe with aluminium tape Position pipe thermostat and cable
Tape cable to pipe
Insulate pipe ( 20mm max )
Required Accessories
PFP Tape
Alu50 Tape
Product Codes
Features
= Protects hot and cold water pipework that may be
subject to freezing conditions
= Simple, low cost solution for the prevention of burst pipes
= Suitable for both metal and plastic pipe up to 50mm
diameter
= Ready made unit with fitted 1.5m cold lead and 3 pin
plug for simple installation
= Integrated thermostat energises system when
temperature falls below +3OC
= Typical uses: boiler condensate pipes, external water
pipes, waste pipes in unheated areas, lofts,
outbuildings and external waste pipes
38
Length
(m)
Product Code
Voltage
Watts
Price ex
VAT (£)
2
PFP2
230
20
57.68
3
PFP3
230
30
61.25
4
PFP4
230
40
62.35
6
PFP6
230
72
68.31
10
PFP10
230
136
75.35
14
PFP14
230
152
81.57
21
PFP21
230
281
92.87
30
PFP30
230
337
105.00
42
PFP42
230
490
129.87
Alu50
(45m x 50mm)
Aluminium
tape
20.51
PFP tape
(33m x 18mm)
Fixing
tape
6.50
visit www.flexel.co.uk for detailed product info & installation tips
