Product Codes
System Construction
MST Mats, 230V, 500mm wide
Introduction
MST cable mats should be installed in a sand bed or concrete
slab depending on application.
Output
(W)
Product
Code
Area (m2)
Length
(m)
Price ex
VAT (£)
450
MST300/1.5
1.5
3.0
75.82
600
MST300/2.0
2.0
4.0
96.27
900
MST300/3.0
3.0
6.0
125.16
1200
MST300/4.0
4.0
8.0
140.80
1500
MST300/5.0
5.0
10.0
182.11
1800
MST300/6.0
6.0
12.0
214.40
2100
MST300/7.0
7.0
14.0
234.89
2400
MST300/8.0
8.0
16.0
249.91
2700
MST300/9.0
9.0
18.0
284.82
3000
MST300/10.0
10.0
20.0
303.07
3600
MST300/12.0
12.0
24.0
372.47
4500
MST300/15.0
15.0
30.0
418.80
6000
MST300/20.0
20.0
40.0
638.82
Driveway
For driveways intended to take the weight of vehicles we
recommend the cables are installed in a concrete slab for
protection. The cable mats should be installed between 2 layers
of concrete. Install the cable mat over the bottom layer and then
pour the top layer of concrete. The concrete mixture must not
contain sharp stones as these may damage the cable.
ECOFLOOR driveway
R
1
2
3
4
5
6
1. Hardened surface, e.g. interlocking pavement
2. Humidity sensor (water, snow, ice)
3. Sand bed of the interlocking pavement
4. Concrete slab (protects the heating cable from vehicle load)
5. ECOFLOOR MST mat
6. Firm gravel base
Simply melt away the ice and snow.
An ice detector for the economical
control of ice prevention and snow
melting cables used on driveways,
ramps and exterior steps. The use
of an ice detector will reduce
energy consumption by
approximately 80% compared to
control by a simple air thermostat.
R
Ice Detector &
Combined Sensor
The ice detector, equipped with a
combined temperature and moisture
ground sensor, monitors conditions and determines the optimum
switch-on time so that the heating comes on in good time to
prevent ice formation. Unnecessary waste of energy is avoided as the
system is only activated when there is ice or snow present.
Pavement
The cables should be installed in a sand bed just below the
concrete paviour.
ECOFLOOR pavement
R
1
Accessories
2
3
Product
Code
Description
Max
Load
(W)
Price
ex VAT
(£)
IDC100
Single channel automatic
ice detector
3600
220.00
IDC200
Two channel automatic
ice detector
11000
330.00
IDCGS
Combined temperature &
moisture sensor
4
5
275.00
1. Hardened surface, e.g. paviors
2. Humidity sensor (water, snow, ice)
3. Sand fill and the sub-base of the cable
4. ECOFLOOR MST mat
5. Firm gravel base
R
call our sales team on 01592 760928 or email enquiries@flexel.co.uk
