Clears walkways, paths,
pavements and drives
ECOFLOOR®
ice prevention & snow melting cable mat
In the winter months, serious injury can occur from
the formation of ice on work platforms in
warehouse loading bays or on entrance walkways
to busy public buildings etc. This potential hazard
can easily be minimised by installing an ice
prevention system.
Features
In the case of snow fall, an ice prevention system
will quickly melt any snow that falls providing clear
access for pedestrians and vehicles on pavements
and drives.
= 500mm wide mat format with pre-spaced
cables ensure even heat distribution and
ease of installation
MST heating cable mats are rated at 300Watts/m2
and are used for ice and snow melting of outdoor
areas and other applications where the cable mat
is embedded in concrete.
The most common application in industry is
heating of ramp or loading platforms in factories
and warehouses where an ice prevention system
can reduce the risk of accidents and ensure work
can be carried out at all times. There are however,
a variety of applications for ice and snow melting.
All these applications can be kept free from ice
and snow so heavy salting and snow shovelling
are avoided. These include: car parks, garage
driveways, pavements and outdoor steps.
Before
36
= Approved to IEC 60800
= 300W/m2 power density provides
clear, safe access for pedestrians
and vehicles on pavements and drives.
= Suitable under concrete, paviours and asphalt
Technical Detail
= Single conductor cable with full protection screen
= Cold tails: 1x5m with other cold lead
1x5m + length of mat
= 5.0-5.5mm thick cable with UV protective outer jacket
= 230V supply, IP 67 Rated
= Power density - 300W/m2
After
visit www.flexel.co.uk for detailed product info & installation tips
