FLEXEL
self regulating cables for pipe freeze protection
Thermoplastic outer jacket
Tinned copper earth braiding
Thermoplastic insulation
Self regulating heating element
Bus wire 1.23mm2
The ELSR Self Regulating 230V heating cables provide an effective and affordable solution for the freeze
protection of water pipes. They are suitable for use on metal and plastic pipes. Typical applications would be
the protection of boiler condensate pipes, exposed water pipes in the home, farm buildings, stables, garages
and lofts plus many other applications.
ELSR cables are supplied by the metre and can be cut to length on site minimising wastage. The ELSR trace
heating range will not produce dangerous hot spots even when cables are touching or overlapping and the
two power outputs within the range can be used when straight-tracing pipes of between 15mm and 150mm in
diameter.
Advantages
Features
= Easy termination
= Time saving
= Economical
=
=
=
=
To provide pipe freeze protection the ELSR cables
are simply taped along the bottom of the pipe.
For plastic pipes we recommend the use of
aluminium foil tape to provide better heat dispersion.
For maximum protection, trace heated pipes should
always be insulated. A connection kit using crimps
and heat shrink insulation ( kit 4 ) will be required
per circuit. This kit includes components to produce
a cold tail connection to the trace cable and seal
the end.
Technical Detail
=
=
=
=
=
Outer jacket: TPE-O
Bus wire: nickel plated copper
Construction: protective braid and a
thermoplastic outer jacket
Nominal Voltage: 230V
Bend radius: 25mm (min)
Self regulating
Two power outputs: 10W/lm and 20W/lm
Can be cut to length on site
Moisture proof with full length earth braid
Product Codes
self regulating cables
Product Code
Output
W/m at
10oC
Max
Temp
Min
Temp
Max
Circuit
Length
(m)
Price
ex VAT
(£)
ELSR-M-10-BO
10
65
-30
126
10.58
ELSR-M-20-BO
20
80
-10
146
12.47
Accessories
Product
Code
Description
Price ex
VAT (£)
Kit 4
Connection and termination kit
12.65
Alu50
Aluminium Foil Tape
( For plastic pipes ) ( 45m x 50mm )
20.51
PFP tape
Fixing tape, high temp
( 33m x 18mm )
6.50
call our sales team on 01592 760928 or email enquiries@flexel.co.uk
