Joints
Penetrating Item ( s ) F-Rating T-Rating Movement Product System Number
JOINTS — HEAD-OF-WALL ( HW-D SERIES ) ( CONTINUED )
Block wall to underside of flat concrete ( Max . JW = 3 ”)
Block wall to underside of flat concrete or hollow core ( Max JW = 3 ”)
Block wall to underside of flat concrete or hollow core ( Max JW = 3 ”)
2 Hr ◼ 17 % CP 606 HW-D-1078
4-Hr ◼ 12.5 % CFS-S SIL GG HW-D-1103
2-Hr ◼ 33 % CFS-S SIL GG HW-D-1104
NEW Gypsum wall to concrete over metal decking ( Max JW = 2 ”) 1-1 / 2 Hr 22 % CFS-SP WB FM 420 NEW Gypsum wall to concrete over metal decking ( Max JW = 2 ”) 2 Hr 25 % CP 606 FM 421 NEW Gypsum wall to concrete over metal decking ( Max JW = 1 ”) 1-1 / 2 Hr 50 % CFS-SP WB FM 513 NEW Gypsum wall to concrete over metal decking ( Max JW = 2-1 / 2 ”) 2 Hr 40 % CFS-SP WB FM 634
NEW
NEW
NEW
NEW
Gypsum wall to flat concrete ( Max JW = 1 / 2 ”) Similar to HW-D-0757
Gypsum shaft wall to flat concrete ( Max JW = 1 / 2 ”) Similar to HW-D-0824
Gypsum wall to flat concrete ( Max JW = 1 ”) Similar to HW-D-0871
Gypsum wall to flat concrete ( Max JW = 1 ”) Similar to HW-D-0873
JOINTS — HEAD-OF-WALL ( HW-S SERIES )
Gypsum wall to concrete over fluted metal deck ( top-of-wall ) Gypsum wall to concrete over fluted metal deck ( top-of-wall )
Concrete or block wall to concrete over fluted metal deck ( top-of-wall )
Gypsum wall to concrete floor joint ( top-of-wall )
Gypsum wall to concrete floor joint or fluted metal floor / roof deck ( top-of-wall )
Gypsum wall to concrete floor or fluted metal floor / roof deck ( top-of-wall )
Concrete or block wall to concrete floor hollow core concrete ( top-of-wall ) ( Max Joint Height = 0 ”)
Gypsum Wall to bottom of offset I beam with Z-bar extentions ( Max JW = 1 ”)
Gypsum Wall to gypsum ceiling ( Max JW = 1 / 2 ”)
1-1 / 2 Hr 50 % CFS-TTS FM 708
1 or 2 Hr 50 % CFS TTS FM 709
2 Hr 50 % CFS-TTS MD FM 763
2 Hr 50 % CFS-TTS MD FM 764
1 or 2 Hr ◼ FS-ONE MAX HW-S-0036 1 or 2 Hr ◼ FS-ONE MAX HW-S-0037
2 Hr FS-ONE MAX HW-S-0038
1 or 2 Hr FS-ONE MAX HW-S-0039
1 or 2 Hr ◼ CFS-SP WB HW-S-0053
1 or 2 Hr ◼ CP 606 HW-S-0054
2 Hr ◼ CP 606 HW-S-0055
1 or 2Hr CFS-SP WB HW-S-0069
1 Hr
CP 606 FS-ONE MAX
HW-S-0090
NEW Gypsum wall to flat concrete ( head-of-wall ) ( Max JW = 3 / 4 ”) 2 Hr ◼ CFS-TTS HW-S-0133
NEW
Gypsum wall to offset fireproofed I beam to concrete over metal deck ( top-of-wall ) ( Max JW 1-1 / 2 ”)
NEW Gypsum Wall to gypsum ceiling ( Max JW = 1 / 2 ”) 1 Hr
1 or 2 Hr ◼ CFS-TTS MD HW-S-0134
CP 605 bottom of wall sealant
HW-S-0145
NEW Gypsum Wall to concrete over metal decking ( Max JW = 3 / 4 ”) 1 Hr FS-ONE MAX FM 243
JOINTS — WALL-TO-WALL ( WW-D SERIES )
Concrete wall to wall joint ( Max JW = 2 ”)
Concrete wall to wall joint ( Max JW = 1 ”) ( backer rod optional )
Gypsum wall to concrete / block wall joint ( Max JW = 3 / 4 ”)
Concrete wall to wall joint ( Max JW = 2 ”) Gypsum wall to wall joint ( Max JW = 2 ”) Gypsum wall to concrete wall joint ( Max JW = 2 ”)
2 Hr 12.5 % CFS-SP WB WW-D-0017
3 Hr 12.5 % CP 606 WW-D-0032
1 or 2 Hr ◼ 17 %
CP 606 CFS-S SIL GG
WW-D-0040
3 Hr ◼ 6 % CP 606 WW-D-0064 1 or 2 Hr 12.5 % CP 606 WW-D-0067 1 or 2 Hr 12.5 % CP 606 WW-D-0068
CLICK CATEGORY INFO BELOW :
Blank Openings Metallic Penetrants Non-Metallic Pipes * Cables / Cable Trays Insulated Pipes
Miscellaneous Electrical ( Busway )
Miscellaneous Mechanical / Ducts
Mixed Penetrating Items *
Blank Openings Metallic Penetrants Non-Metallic Pipes * Cables Cable Trays Insulated Pipes
Miscellaneus Electrical ( Busway )
Miscellaneous Mecahnical / Ducts *
Mixed Penetrating Items *
Blank Openings
Metallic Penetrations
Non-Metallic Pipes * Cables Insulated Pipes
Miscellaneous Mechanical / Duct Penetrations
Mixed Penetrating Items *
Metallic Penetrations
Non-Metallic Pipes * Cables Insulated Pipes
Miscellaneous Mechanical / Duct Penetrations
Mixed Penetrating Items *
Bottom of Wall ( BW-S Series )
Continuity Head-of- Wall ( CJ-D Series )
Floor-to-Floor ( FF-D Series )
Floor-to-Wall ( FW-D Series )
Intertek Series ( ASTM E 1966 )
Head-of-Wall ( HW-D Series )
Head-of-Wall ( HW-S Series )
Wall-to-Wall ( WW-D Series )
Wall-to-Wall ( WW-S Series )
Perimeter Fire Barrier Joints ( Curtain Wall ) – ASTM E2307
Joints Steel-Framed Floors Wood-Framed Floors Framed ( Gypsum ) Walls Concrete Floors / Walls
Concrete wall to wall joint ( Max JW = 3 / 4 ”) 2 Hr 17 % CP 606 WW-D-0082 50
Wall-to-Wall ( WW-D Series ) ( continued ) ➜
