JOINTS — WALL-TO-WALL ( WW-D SERIES ) ( CONTINUED )
Gypsum wall to concrete wall joint ( requires backer rod ) ( Max JW = 1 ”)
Concrete wall to wall joint ( Max JW = 2 ”)
Concrete wall to wall joint ( Max JW = 1 ”)
Concrete wall to wall joint ( Max JW = 2 ”) optional max 1 ” conduits
Concrete wall to wall joint ( Max JW = 3-1 / 2 ”)
Concrete wall to wall joint ( Max JW = 3-3 / 4 ”)
Concrete wall to wall joint ( Max JW = 2 ”)
Concrete wall to wall joint ( Max JW = 3 ”)
Concrete wall to wall joint ( Max JW = 3-1 / 2 ”)
Concrete wall to wall joint ( Max JW = 3 ”)
Concrete wall to wall joint ( Max JW = 3 ”)
1 or 2 Hr 19 % CP 606 WW-D-0105
3 Hr 18 % CFS-S SIL GG WW-D-0140
2 Hr ◼ 25 % CFS-S SIL GG WW-D-0141
2 Hr 12.5 % CP-606 WW-D-0220
3 Hr 14 % CFS-S SIL GG WW-D-1011
2 Hr ◼ 7 % CP 606 WW-D-1012
4 Hr 12.5 % CFS-S SIL GG WW-D-1047
2 Hr ◼ 17 % CP 606 WW-D-1080
2 Hr 14 % CFS-SP WB WW-D-1084
4 Hr ◼ 12.5 % CFS-S SIL GG WW-D-1128
2 Hr ◼ 33 % CFS-S SIL GG WW-D-1129
|
Non-Metallic Pipes *
Cables / Cable Trays
Insulated Pipes
Miscellaneous Electrical ( Busway )
Miscellaneous Mechanical / Ducts
Mixed Penetrating Items *
Blank Openings
Metallic Penetrants
Non-Metallic Pipes *
Cables
Cable Trays
Insulated Pipes
Miscellaneus Electrical ( Busway )
Miscellaneous Mecahnical / Ducts *
Mixed Penetrating Items *
Blank Openings
|
Framed ( Gypsum ) Walls Concrete Floors / Walls |
||
|
JOINTS — WALL-TO-WALL ( WW-S SERIES )
Concrete wall to wall joint ( Max JW = 1 ”)
Concrete wall to gypsum wall ( gyp sitting on top of concrete ) ( Max JW = 3 / 4 ”)
Gypsum shaft wall to concrete wall ( Max JW = 1 ”)
2 Hr ◼
1 or 2 Hr
CP 606 CFS-S SIL GG
CP606 CFS-S SIL GG
WW-S-0042
WW-S-0048
1 or 2 Hr CP 606 WW-S-0059
|
Metallic Penetrations
Non-Metallic Pipes *
Cables
Insulated Pipes
Miscellaneous Mechanical / Duct Penetrations
|
Wood-Framed Floors |
|||
|
Gypsum wall to concrete or block wall ( Max JW = 3 / 4 ”)
Gypsum chase wall to concrete or block wall ( Max JW = 3 / 4 ”)
|
1 or 2 Hr ◼ CFS-TTS WW-S-0074
1 or 2 Hr ◼ CFS-TTS WW-S-0075
|
Mixed Penetrating Items *
Metallic Penetrations
|
|
Penetrating Item ( s ) F-Rating T-Rating L-Rating Product
PERIMETER FIRE BARRIER JOINTS ( CURTAIN WALL ) — ASTM E2307
|
System Number [ Similar FM Approved System ] |
