Penetrating Item ( s ) F-Rating T-Rating L-Rating Product
MIXED PENETRATING ITEMS IN FRAMED ( GYPSUM ) WALLS * ( CONTINUED )
Insulated or non-insulated metallic , non metallic pipes , and cable bundle ( AS varies )
Max . 2 ” steel , cast iron , conduit , EMT , flexible gas piping , or ENT , max . 4 ” cable bundle
Insulated or non-insulated metallic , non metallic pipes , and cable bundle ( AS varies ) ( unframed or framed opening )
Multiple HVAC Line Sets ( max qty 3 ) bundled together ( AS = 0 ” to 1-1 / 2 ”)
Misc . bundle consisting of cables , metal pipe , ENT ( AS = 0 ” to 1 ”)
Cable Bundle and Metallic Pipe through CP 653 Speed Sleeve
Insulated or non-insulated metallic , non-metallic , cable bundles ( AS varies )
Insulated or non-insulated steel , cast iron , copper , conduit or EMT pipes , plastic pipe , cable tray or cables ( single or bundled ) ( AS varies )
ABS fiber optic cable tray ( 12 ” x 4 ”), cable bundle ( various cables ), Max . 2 ” fiber optic raceway ( PVC ) ( AS varies )
Insulated or non-insulated metallic , non-metallic , cable bundles ( AS varies )
Fiberglass , aluminum or steel cable tray ( 18 ” x 4 ”), cable bundle ( various cables ), non-insulated steel , cast iron , EMT , conduit , or copper pipe , non-metallic pipe ( install both sides ) ( AS varies )
HVAC Line Set ( AS varies )
Max . 24 ” x 4 ” Open aluminum cable ladder , One or more Max . 4 ” cable bundles ( AS varies )
Max . 3 ” EMT , Max . 2 ” Copper , Various cables
Max . 6 ” Steel tube ( Min . 16 Ga ) with Max . three low voltage plenum cables ( AS varies )
Max . 1 ” copper with optional Various types of cable
Framed ( Gypsum ) Walls
System Number [ Similar FM Approved System ]
1 or 2 hr FS-ONE MAX W-L-8065
1 or 2 Hr FS-ONE MAX W-L-8071
1 or 2 Hr ◼ FS-ONE MAX W-L-8079
1 or 2 Hr
1 or 2 Hr
CP648E / 1-3 / 4 ” w / Ret Collar
CP 648E / 1-3 / 4 ” w / Ret Collar
W-L-8081
W-L-8082
1 or 2 Hr Speed Sleeve W-L-8086
1 or 2 Hr ◼ Firestop Block W-L-8087
1,2,3 or 4 Hr
Firestop Block
W-L-8093
1 or 2 Hr ◼ Firestop Block W-L-8094
1 or 2 Hr ◼ Firestop Block W-L-8095
2 Hr CFS-COS W-L-8105
1 or 2 Hr CFS-SL SK W-L-8110
1 or 2 Hr
CFS-COS CFS-BL CP 653 ( BA ) CFS-CC
W-L-8125
2 Hr FS-ONE-MAX FM 288
1 / 2 Hr FS-ONE MAX FM 347
1 / 2 or 2 Hr
CFS-S SIL GG FM 677
