Penetrating Item ( s ) F-Rating T-Rating L-Rating Product
METALLIC PENETRANTS IN FRAMED ( GYPSUM ) WALLS ( CONTINUED )
Max . 3 / 4 ” steel , cast iron , conduit , or EMT pipe , or max . 1 / 2 ” copper pipe ( AS = min 0 ”)
NEW 8 ” Aluminum Tubing ( 0.060 in . Wall thickness ) ( AS 1 / 2 ” to 1-1 / 2 ”) Canada Only
NEW Max 2 ” Steel , Cast-iron , steel conduit , EMT , or Copper . ( AS 1 / 4 ” -5/ 8 ”) V 497 wall type
NEW Max . 12 ” steel pipe
NEW Max 12 ” steel pipe with max 18 ” steel sleeve ( AS 3 / 4 ” to 4-1 / 2 ”) NEW Max . 12 ” Steel pipe ( AS 0 ” to 1 / 4 ”) NEW Max . 1 ” EMT ( Max . qty . 8 ) ( AS 1 / 2 ” to 1 ”) NEW Max . 2 ” EMT ( Max . qty . 15 ) NEW Max . 4 ” Copper ( AS 1 / 4 ” to 1-5 / 8 ”) NEW Max 4 ” Copper with steel sleeve ( AS 0 ” to 1-1 / 2 ”)
Framed ( Gypsum ) Walls
System Number [ Similar FM Approved System ]
1 or 2 Hr ◼ ◼ CFS-D 1 ” W-L-1506
2 Hr FS-ONE MAX W-L-1550
1 Hr FS-ONE MAX W-L-1551
1 Hr FS-ONE MAX FM 286 2 Hr FS-ONE MAX FM 290 1 / 2 Hr FS-ONE MAX FM 291 1 Hr FS-ONE MAX FM 293 1-1 / 2 Hr FS-ONE MAX FM 328 1 / 2 Hr FS-ONE MAX FM 339 1 / 2 Hr FS-ONE MAX FM 343
NEW |
Max . one or more 1 ” or 2 ” EMT ( AS 0 ” to 4-1 / 2 ”) |
1 / 2 or
1-1 / 2 Hr
|
CP 620 |
FM 423 |
NEW |
Max . 4 ” Steel conduit |
3 / 4 Hr |
CP 618 |
FM 597 |
NEW |
Max . 2 ” Steel pipe , rigid steel conduit or EMT ( Max Qty . 5 ) |
1 / 2 or
2 Hr
|
CFS-S SIL GG |
FM 678 |
NEW |
Max . 6 ” Copper pipe ( AS = 0 ” to 2-1 / 4 ”) |
1 or 2 Hr |
FS-ONE MAX |
FM 689 |
NEW Max 6 ” Copper pipe with steel sleeve ( AS = 1 / 2 ” to 1-1 / 4 ”)
NEW
NEW
NON-METALLIC PIPES IN FRAMED ( GYPSUM ) WALLS *
Max . 2 ” PP ( Sch 80 ) ( c , v ) w / 1 ” AB / PVC or 1-1 / 2 ” glass or mineral fiber pipe insulation ( c , v ) ( AS = 0 ” to ¼ ”)
Max . 2 ” PP ( Sch 80 ) ( c , v ) ( AS = 3 / 16 ” to 5 / 16 ”)
Max . 2 ” PP ( Sch 80 ), Aquatherm Greenpipe ( SDR 7.4 or 11 ), Aquatherm Greenpipe ( SDR 9 or 11 ), Napsiys PVC ( c , v ) ( AS = 0 ” to 5 / 8 ”)
Max . 125 mm Fusiotherm ( SDR 11 or SDR 7 . 4 with Fraser ) PP manufactured by Aquatherm ( AS = 0 ” to ½ ”) ( Canada Only )
Max . 2 ” ENT ( c ) ( AS = 3 / 4 ”)
Max . 10 ” PVC , CPVC , max . 6 ” ABS , FRPP or max . 4 ” PVDF ( c , v ) ( AS = 0 ” to 1 / 2 ”) Max 4 ’ PEX
Max . 6 ” PVC , CPVC , ABS or FRPP ( c , v ) ( sleeve optional ) ( AS = 1 / 4 ” to 1-1 / 4 ”)
Max . 2 ” PVC or CPVC ( c ) ( AS = 3 / 4 ” to 1-1 / 4 ”)
Max . 2 ” PVC or CPVC ( c , v ) ( sleeve Optional ) ( AS = 1 / 4 ” to 11 / 16 ”) ( angled penetrant allowed )
Max . 2 ” Fiber Optic Raceway ( Innerduct ) or ENT pipe ( AS = 1 / 4 ” to 7 / 8 ”)
Max . 2 ” PVC or CPVC ( c ) ( sleeved ) ( AS = 1 / 2 ” to 1 ”)
Max . 1 ” PEX ( c )( sleeved ) ( AS = 1 / 2 ” to 1-3 / 8 ”) ( angled penetrant allowed )
Max . 1-1 / 2 ” ABS ( c , v ) ( AS = 3 / 8 ” to 3 / 4 ”)
Max . 1 ” Fiber Optic Raceway ( Innerduct ) ( AS = 1 / 4 ” to 3 / 8 ”)
Max . 4 ” PVC or CPVC ( c , v ) ( shaft wall ) ( AS = 0 ” to 1 / 4 ”) Max . 2 ” PVC ( c , v ) ( AS = 9 / 16 ”)
4 Hr FS-ONE MAX FM 695
1 or 2 Hr ◼
CP 648E w / Retaining Collar
W-L-2043
1 or 2 Hr CP 648S W-L-2044
1 or 2 Hr ◼ CP 643N W-L-2045
1 or 2 Hr ◼ CP 648E / 1-3 / 4 ” W-L-2048
1 or 2 Hr ◼ ◼ FS-ONE MAX W-L-2075
1 or 2 Hr ◼
CP 643N CP644
W-L-2078
1 or 2 Hr CP 643N W-L-2084
1 or 2 Hr ◼ ◼ FS-ONE MAX W-L-2098
1 or 2 Hr FS-ONE MAX W-L-2128
1 or 2 Hr ◼ ◼ FS-ONE MAX W-L-2165
4 Hr FS-ONE MAX W-L-2184
1 or 2 Hr ◼ FS-ONE MAX W-L-2186
1 Hr FS-ONE MAX W-L-2196
1 Hr FS-ONE MAX W-L-2197 2 Hr CP 643N W-L-2217 2 Hr ◼ CP 648E / 1 ” W-L-2232
