Penetrating Item ( s ) F-Rating T-Rating L-Rating Product
METALLIC PENETRANTS IN FRAMED ( GYPSUM ) WALLS ( CONTINUED )
Max . 2 ” EMT or steel conduits ( one or more ) ( AS varies )
Max . 8 ” steel , cast iron , max . 6 ” conduit , max . 4 ” copper , EMT or max . 2 ” flexible steel conduit ( sleeved ) ( shaft wall ) ( AS = 1 / 4 ” to 1-5 / 8 ”)
Max . 8 ” steel , cast iron , max . 6 ” conduit , max . 4 ” copper , EMT or max . 2 ” flexible steel conduit ( sleeved ) ( shaft wall ) ( AS = 0 ” to 1-7 / 8 ”)
Max . 1 ” flexible steel conduit ( AS = 0 ” to ¾ ”)
Max . 2 ” aluminum or steel flexible conduit ( AS = 0 ” to 1 ”)
Max . 6 ” steel , cast iron , steel conduit or max . 3 ” copper , or max . 4 ” EMT pipe ( one or more ) ( AS varies )
Max . 6 ” steel , cast iron , steel conduit or max . 3 ” copper , or max . 4 ” EMT pipe ( one or more ) ( AS varies )
Max . 2 ” Steel Conduit or EMT ( Multiple in 30 ” x12 ” opening ) ( AS varies )
Max . 4 ” steel , cast iron , copper , conduit , or EMT ( AS = 0 ” to 7 / 8 ”)
Max . 4 ” steel , cast iron , copper , conduit or EMT pipe ( AS = 0 ” to 7-7 / 8 ”)
Max . 4 ” steel , cast iron , copper , conduit , or EMT ( AS = 0 ” to ½ ”)
Max . 30 ” steel , cast iron , max . 6 ” copper , conduit or max . 4 ” EMT pipe ( AS = 0 ” to 1 ” or 2 ”)
Max . 4 ” steel , cast iron , conduit , or EMT ( AS = 0 ” to ½ ”)
Max . 4 ” cast iron with stainless steel “ no-hub ” coupling ( AS = 0 ” to 1 ”)
Max . 24 ” steel , cast iron , 6 ” copper , steel conduit , or 4 ” EMT ( AS = 0 ” to 7 / 8 ”) ( AS = 0 ” to 1-1 / 2 ”)
Max . 8 ” steel , cast iron , max . 6 ” steel conduit , max . 4 ” copper or EMT ( AS = 0 ” to 7-7 / 8 ”)
Max . 8 ” steel , cast iron , 6 ” copper , 6 ” steel conduit , or EMT ( shaft wall ) ( AS = 0 ” to 7 / 8 ”)
Multiple max . 2 ” steel , steel conduit , or EMT ( AS varies )
Max . 12 ” steel , cast iron , 6 ” copper , EMT or steel conduit ( AS = 0 ” to 3-7 / 8 ”)
Max . 8 ” steel , cast iron , max . 6 ” steel conduit , max . 4 ” copper or EMT ( U336 or U366 wall ) ( AS = 0 ” to 1-7 / 8 ”)
Multiple max . 4 ” steel , steel conduit , or EMT ( AS varies )
Max . 3 ” steel , steel conduit , EMT ; max . 1 ” copper or flexible steel conduit ( membrane penetration ) ( AS varies )
Max . 2 ” steel , cast iron , steel conduit , or EMT running vertically through plane of wall on one side ( AS = 0 ” to 3 / 4 ”)
Max . 1 ” steel conduit or EMT with steel junction box ( AS = 0 ” to 1-1 / 8 ”)
Max . 3 ” steel , cast iron , steel conduit , or EMT
Medical Gas station Outlet
Max . 1 ” single or bundled fledxible steel conduits ( AS = 0 ” to 3 ”)
Max . 8 ” steel , cast iron , 6 ” steel conduit , 4 ” copper or EMT w / sheet metal sleeve ( AS = 0 ” to 1-7 / 8 ”)
Max . 4 ” Aluiminum tube ( c ) ( AS = min 3 ”)
Framed ( Gypsum ) Walls
System Number [ Similar FM Approved System ]
1 or 2 Hr ◼ FS-ONE MAX W-L-1176
1 or 2 Hr FS-ONE MAX W-L-1205
1 or 2 Hr FS-ONE MAX W-L-1206
1 Hr FS-ONE MAX W-L-1214
1 or 2 Hr FS-ONE MAX W-L-1243
2 Hr CP 637 W-L-1247
1 Hr CP 637 W-L-1248
1 or 2 Hr Fire Foam W-L-1249
1,2,3 , or 4 Hr
◼
FS-ONE MAX CP 606 ( 1,2 , or 3 hr only )
W-L-1252
1 or 2 Hr ◼ Fire Foam W-L-1289
1 or 2 Hr ◼ CP 606 W-L-1290
1 or 2 Hr ◼ CP 606 W-L-1297
1 or 2 Hr ◼
FS-ONE MAX CP 606
W-L-1304
1 or 2 Hr FS-ONE MAX W-L-1359
1 or 2 Hr CFS-S SIL GG W-L-1360
1 or 2 Hr ◼ CP 675T W-L-1367
2 Hr FS-ONE MAX W-L-1380
1 or 2 Hr
FS-ONE MAX CP 606 ( 1 Hr only )
W-L-1389
1 or 2 Hr ◼ FS-ONE MAX W-L-1392
2 Hr ◼ FS-ONE MAX W-L-1406
1 or 2 Hr FS-ONE MAX W-L-1408
1 or 2 Hr
FS-ONE MAX CP 606 CP 618 CFS-S SIL GG
W-L-1410
1 Hour FS-ONE MAX W-L-1412
1 or 2 Hr FS-ONE MAX W-L-1440
1 or 2 Hr Speed Sleeve W-L-1441 1 or 2 Hr ◼ CP 617 W-L-1462
1 or 2 Hr FS-ONE MAX W-L-1464
1 or 2 Hr ◼
FS-ONE MAX CP 606
W-L-1465
1 or 2 Hr ◼ ◼ Firestop Block W-L-1497
