Penetrating Item ( s ) F-Rating T-Rating L-Rating W-Rating Product
NON-METALLIC PIPES IN CONCRETE FLOORS / WALLS * ( CONTINUED )
Max . 2 ” Glass pipe ( AS = 0 ” to 1-3 / 4 ”)
Max 2 ” CPVC ( closed ) ( includes hollow core ) ( AS = ½ ” to 1-1 / 8 ”)
Max . 2 ” Aquatherm Greenpipe PP-R ( SDR 7.4 ), Bluepipe PP-RCT ( SDR 9 ), Niron PP-RCT ( by Nupi Americas ( SDR 7.3 ), Aquatechnik PP-RCT ( SDR 7.4 ) and Uponor PP ( SDR 9 ), ( AS = 5 / 16 ”) UL only
Max . 2 ” Aquatherm Greenpipe PP-R ( SDR 7.4 ), Bluepipe PP-RCT ( SDR 9 ), Niron PP-RCT ( by Nupi Americas ( SDR 7.3 ), Aquatechnik PP-RCT ( SDR 7.4 ) and Uponor PP ( SDR 9 ), ( AS = 5 / 16 ”) 50 Pa Canada only
Max . 1-1 / 4 ” Orion Polystar PP , max . 1-1 / 4 ” Cosmoplast PP-R , max . 1-1 / 4 ” Coprax PP-R plastic pipe ( c ) ( AS = 0 ” to 2 ”)
Max . 2 ” ( 63mm ) PP ( SDR 11 ) Fusiotherm or Polystar CT-White ( c ) ( AS = 3 / 16 ” to 13 / 16 ”)
Max . 6 ” Cosmoplast PP-R , HPDE or max . 4 ” Coprax PP-R plastic pipe ( c ) ( AS varies )
Concrete Floors / Walls
System Number [ Similar FM Approved System ]
2 Hr CFS-S SIL GG C-AJ-2675
3 Hr 2-1 / 2 Hr ◼ ◼
CFS-S SIL GG CFS-S SIL SL
C-AJ-2676
2 Hr ◼ CP 648E / 1-3 / 4 ” C-AJ-2677
2 Hr ◼ CP 648E / 1-3 / 4 ” C-AJ-2677
2 Hr ◼ FS-ONE MAX C-AJ-2700
2 Hr ◼ CP 648E-1-3 / 4 ” C-AJ-2712
2 Hr ◼ CP 648E-1-3 / 4 ” C-AJ-2770
NEW 3 ” Nominal Pex Tubing ( SDR 9 ) ( AS 3 / 8 ” to 1-1 / 8 ”) 2 Hr ◼ ◼ ◼ FS-ONE MAX C-AJ-2827
NEW
NEW
NEW
NEW
NEW
Max . 3 ” Aquatherm Greenpipe PP-R ( SDR 7.4 or 11 ), Bluepipe PP-RCT ( SDR 9 or 11 ) Niron PP-RCT ( by Nupi Americas ( SDR 7.3 , 9 , or 11 ), Aquatechnik PP-RCT ( SDR 7.4 or 11 ) and Uponor PP-RCT ( SDR 9 or 11 ), CPVC . ( AS 0 ” to 1 / 2 ”) 50 Pa
Max . 6 ” Aquatherm Greenpipe PP-R ( SDR 7.4 or 11 ), Bluepipe PP-RCT ( SDR 9 or 11 ) Niron PP-RCT ( by Nupi Americas ( SDR 7.3 , 9 , or 11 ), Aquatechnik PP-RCT ( SDR 7.4 or 11 ) and Uponor PP-RCT ( SDR 9 or 11 ), PVC . Optional Steel Sleeve ( AS 0 ” to 3 / 4 ”) See system for AS requirments 50 Pa
Max 18 ” PVC , XFR PVC , CPVC , Corazan CPVC ( AS 1 / 4 ” to 1-1 / 2 ”) Canada Only
Max . 6 ” PVC , CPVC ( SDR 13 . 5 ), Rigid Nonmettalic Conduit ( AS Min . 2 ”) ( MSO 900 sq . in .)
Max . 4 ” HDPE ( SDR 11 ) and optional 6 ” Steel Sleeve ( AS varies )
2 Hr ◼ ◼
2 or 3 Hr ◼ ◼
2 or 3 Hr ◼ ◼
2 Hr
CP 648E / 1-3 / 4 ”, FS-ONE MAX
CP 648E / 1-3 / 4 ”, FS-ONE MAX
CP 648E / 1-3 / 4 ” CP 648E / 1 ”
CFS-COS CP 643N
C-AJ-2830
C-AJ-2831
C-AJ-2836
C-AJ-2885
2 Hr ◼ 648E / 1-3 / 4 ” C-AJ-2887
NEW Max . 4 ” Polybutyline ( PB ) ( AS 0 ” to 5 / 8 ”) US only 3 Hr ◼ ◼ 648E / 1-3 / 4 ” C-AJ-2897 NEW Max . 8 ” Polybutyline ( PB ) ( AS 0 ” to 1-1 / 4 ””) 3 Hr ◼ ◼ 648E / 1-3 / 4 ” C-AJ-2898
NEW
NEW
Max 2 ” PVC , 2 ” XFR-PVC , 2 ” Napsys-HR PVC ( AS 0 ” to 1-1 / 4 ”) Canada only 50 Pa
Max . 2 ” PP , CPVC , Aquatherm Greenpipe PP-R ( SDR 7.4 or 11 ), Bluepipe PP-RCT ( SDR 9 or 11 ) Niron PP-RCT ( by Nupi Americas ( SDR 7.3 , 9 , or 11 ), Aquatechnik PP-RCT ( SDR 7.4 or 11 ) and Uponor PP-RCT ( SDR 9 or 11 ) with 1-1 / 2 ” thick Glass Fiber Insulation ( AS = 0 ” to 5 / 8 ”) 50 Pa Canada onlly
Max . 3 ” PVC or CPVC ( c , v ) ( hollow core ) ( AS = 1 / 4 ”)
Max . 4 ” PVC or CPVC ( c , v ) ( hollow core ) ( AS = 1 / 4 ”) Max . 2 ” PVC or CPVC ( c , v ) ( hollow core ) ( AS = 5 / 16 ”)
Max . 2 ” PVC , CPVC , or Rigid Nonmetallic Conduit ( c ) ( hollow core )( AS = 0 ” to 1-5 / 8 )
Max . 2 ” PVDF ( c , v ) ( sleeved ) ( 6 ” concrete ) ( AS = 0 ” to 5 / 8 ”)
Max . 4 ” PVC or CPVC ( c , v ) ( 6 ” concrete ) ( includes hollow core ) ( AS = 0 ” to ½ ”)
Max . 6 ” PVC , CPVC or ABS ( c , v ) ( hollow-core ) ( AS = 0 ” to ½ ”)
Bundle of Max . 1 ” PVC , RNC , ENT , or PEX ( c ) ( max qty = 6 ) ( hollow core ) ( AS = 0 “ to 1-1 / 2 ”)
Max . 2 ” PVC , CPVC or PEX ( c ) ( hollow core ) ( AS = 1 / 8 “ to 1 / 2 ”)
2 Hr FS-ONE MAX C-AJ-2900
2 Hr ◼
2 Hr ◼
CP 648E / 1-3 / 4 ” CP 648S
CP 648E / 1-3 / 4 ” CP 648S
C-AJ-2924
C-BJ-2011
2 Hr ◼ CP 648E / 1-3 / 4 ” C-BJ-2012
2 Hr ◼ ◼
CP 648E / 1 ” CP648S
C-BJ-2013
2 Hr ◼ FS-ONE MAX C-BJ-2014
4 Hr ◼
4 Hr ◼
CP 648E / 1-3 / 4 ” w / Ret Collar
CP 648E / 1-3 / 4 ” w / Ret Collar
C-BJ-2016
C-BJ-2017
2 Hr ◼ CP 643N C-BJ-2021
3-Hr ◼ FS-ONE MAX C-BJ-2028
3 Hr ◼ FS-ONE MAX C-BJ-2040
