NON-METALLIC PIPES IN CONCRETE FLOORS / WALLS * ( CONTINUED )
Max . 3 ” PVC or CPVC ( c , v ) ( AS = 3 / 16 ” to 5 / 16 ”)
Max . 4 ” PVC or CPVC ( c , v ) ( AS = 3 / 16 ” to 5-5 / 16 ”)
Max . 4 ” PVC or CPVC ( c , v ) ( AS = 3 / 16 to 5 / 16 ”)
Multiple 2 ” and 1 ” ENT ’ s ( max . qty 6 ) ( inc . Hollow Core ) ( AS varies )
Multiple 2 ” PVC , CPVC , RNC , ENT , max . 1 ” OFR , PEX ( c ) ( sleeve optional ) ( AS varies )
Maximum 10 ” FRPP ( c , v ) ( AS = 0 ” to 3-3 / 8 ”)
Maximum 4 ” ABS , PVC , or CPVC ( c , v ) ( AS = 3 / 4 ”)
Nominal 10 ” or 12 ” PVC or CPVC ( c , v ) ( AS = 1 / 4 ” to 1 ”)
Max . 4 ” ABS , PVC , or CPVC ( c , v ) nonsymmetrical installation ( AS = 0 ” to ½ ”)
Max . 4 ” ABS , PVC , or CPVC ( c , v ) ( AS = 0 ” to ½ ”)
Max . 2 ” FlowGuard Gold or max . 3 ” Blazemaster CPVC ( c ) ( AS = 1 / 4 ” to 1-1 / 4 ”)
Max . 4 ” dia bundle beverage lines ( PE ) with AB / PVC Insulation ( AS = 3 / 16 ” to 1-13 / 16 ”)
Max . 6 ” CPVC ( Sch 80 ) ( c ) ( AS = 0 ” to 3 / 8 ”)
Max . 4 ” ABS , PVC , or CPVC ( c , v ) ( AS = varies )
Max . 4 ” PVC , ABC , CPVC , FRPP , or RNC ( closed or vented ) ( AS = varies )
Max . 4 ” PVC , ABC , CPVC , FRPP , or RNC ( closed or vented ) ( AS = varies )
Max . 2 ” PVC , CPVC ( c , v ), RNC , Aquatherm Greenpipe PP-R ( SDR 7.4 or 11 ), Bluepipe PP-RCT ( SDR 9 , 11 or 17.6 ) Niron PP-RCT ( by Nupi Americas ( SDR 7.3 , 11 , or 17 ), Aquatechnik PP-RCT ( SDR 7.4 , 11 or 17.6 ) and Uponor PP-RCT ( SDR 9 or 11 ) ( closed ) ( sleeve optional ) ( AS w / sleeve = ¼ ” to 1-3 / 8 ”) ( AS w / o sleeve = 0 ” to 1-5 / 8 ”)
Max . 4 ” PVC , CPVC , or ABS ( closed or vented ) ( sleeve optional on pipes 3 ” and smaller ) ( AS varies ) ( bottom side access )
Nom . 6 ” PVC , CPVC , or RNC ( closed or vented ) ( AS = 1 / 2 ” to 1 ”)
Max . 5 ” Fusiotherm ( c , v ) or 4 ” Orion Polystar PP plastic pipe ( c ) ( AS = 0 ” to 1 ”)
Max . 2 ” Fusiotherm PP ( c , v ) or Orion Polystar PP plastic pipe ( c ) ( AS = 0 ” to 5 / 8 ”)
Max . 2 ” Fusiotherm , Climatherm ( c , v ) or Orion Polystar PP plastic pipe ( c ) ( AS = 0 ” to 5 / 16 ”)
Max . 4 ” PVC , ABS , CPVC , or FRPP ( c , v ) ( 2-1 / 2 ” concrete ) ( AS = 0 ” to 3-1 / 2 ”)
Max . 4 ” PVC , ABS , CPVC , FRPP ( c , v ) ( 2-1 / 2 ” concrete ) ( AS = 0 ” to 3-1 / 2 ”)
Max . 2 ” PVC / CPVC with 1 ” glass fiber pipe insulation ( c ) ( AS = 3 / 16 ” to 1-1 / 8 ”)
Max . 2 ” FRPP or PVDF ( c , v ) ( AS = 5 / 16 ”)
Max . 2 ” PVC , CPVC , RNC , ENT and 1 ” PEX ( 2-1 / 2 ” concrete ) ( AS = 0 ” to 1-5 / 8 ”)
Cable bundle ( various cables ) in flexible nylon raceway ( PVC sleeve optional ) ( AS = 0 ” to 3 ”)
Cable bundle ( various cables ) in flexible nylon raceway ( steel sleeve optional ) ( AS = 0 ” to 3 ”)
Max . 4 ” PEX mfg by Uponor with ½ ” glass fiber Insulation removed through firestop ( AS = 0 ” to 7 / 8 ”)
3 Hr ◼
2 Hr
CP 648E / 1 ” or 1-3 / 4 ”, or CP648S
CP 648E / 1-3 / 4 ” Fire Foam
C-AJ-2372
C-AJ-2392
2 Hr ◼ CP 648E / 1-3 / 4 ” C-AJ-2393
3 Hr ◼
CP 648E / 1-3 / 4 ” w / Ret Collar
C-AJ-2402
2 Hr FS-ONE MAX C-AJ-2407
3 Hr ◼
CP 648E / 1-3 / 4 ” w / Ret Collar w / CP 620
C-AJ-2409
3 Hr CP 648E / 1-3 / 4 ” C-AJ-2419
3 Hr ◼ CP 648E / 1-3 / 4 ” C-AJ-2420
3 Hr ◼
2 Hr ◼
CP 648E / 1-3 / 4 ” w / Ret Collar
CP 648E / 1 ” w / Ret Collar
C-AJ-2434
C-AJ-2435
3 Hr ◼ FS-ONE MAX C-AJ-2451
2 Hr CP 648E / 1-3 / 4 ” C-AJ-2468
2 Hr ◼ CP 643N C-AJ-2469
2 Hr ◼ ◼ CP 648S C-AJ-2488
2 Hr ◼
2 Hr ◼
2-Hr ◼ ◼ ◼
CP648S CP620
CP648S CP620
FS-ONE MAX ( Add CFS-S SIL GG or CFS-S SIL SL for W-rating )
C-AJ2-565
C-AJ-2566
C-AJ-2567
2 Hr CP 648S C-AJ-2569
2-Hr ◼ CP 648S C-AJ-2570
2-Hr
◼
CP 648E / 1-3 / 4 ” w / Ret Collar
C-AJ-2599
2-Hr ◼ CP643N C-AJ-2600
2-Hr
2 Hr
2 Hr
◼
CP 648E / 1-3 / 4 ” w / Ret Collar
CP 637 CP 643N
CP 643N ( 28ga cover plate )
C-AJ-2613
C-AJ-2630
C-AJ-2631
2 Hr ◼ FS-ONE MAX C-AJ-2632
2 Hr ◼ CP 648E / 1-3 / 4 ” C-A-J2639
2 Hr ◼ ◼ FS-ONE MAX C-AJ-2647
3 Hr CP 618 C-AJ-2659
2 Hr Firestop Plug C-AJ-2660
2 Hr ◼
CP 648E / 1-3 / 4 ” w / Ret Collar
C-AJ-2674
|
