LAMPS AND COMPONENTS
SENSORS
www.elmarkholding.eu
INFRARED MOTION SENSOR ST10A
99DS107
INFRARED MOTION SENSOR ST15
99DS108
908
IP40
INFRARED MOTION SENSOR ST10A / ST15
Catalogue number Type Detection range Rated load Detection distance Colour body Length
(mm) Width
(mm) Height
(mm) Packing/Box
(pcs)
99DS107 ST10A 180° ESL - 300W, IL - 1200W 5-12m white 87,4 120 144 1/30
99DS108 ST15 180° ESL - 300W, IL - 1200W max.12m white 80 117,2 31,5 1/50
Time-Delay: 10sec ± 3sec to 7min ± 2min (adjustable) | Ambient light: <3 - 2000lux (adjustable) | Detection motion speed: 0.6 - 1.5m/s | Installation height: 2.2 - 4m
50/60
Hz
3+0
standard
+extended
3
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
