LAMPS AND COMPONENTS
www.elmarkholding.eu
SENSORS
LIGHT-CONTROL SENSOR ST303 LIGHT-CONTROL SENSOR ST302
99DS300 99DS301
LIGHT-CONTROL SENSOR ST300
LIGHT-CONTROL SENSORS ST36 LIGHT-CONTROL SENSOR ST308
99ds405 99DS302
99DS404
IP44
IP65
LIGHT-CONTROL SENSORS
Catalogue number Type Rated current Colour body Ambient light Length
(mm) Width
(mm) Height
(mm) Packing/Box
(pcs)
99DS404 ST300 10A white 3-500LUX(adjustable) IP44 35 70 108,6 1/50
99DS300 ST303 25A white <5 - 50lux (adjustable) IP44 70,5 78,3 - 1/50
99DS301 ST302 10A white <5 - 50lux (adjustable) IP44 76,7 63 - 1/100
99DS405 ST36 6A white <5 - 15lux (adjustable) IP44 100 200 - 1/100
99DS302 ST308 20A white <2 - 100lux (adjustable) IP65 35 66 90 1/100
99DS404 - Timer Built-in from 1-9 hours
50/60
Hz
3+0
standard
+extended
3
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
