ELMARK Lighting 2019 Lighting_2019 | Página 506

LAMPS AND COMPONENTS
SENSORS
www.elmarkholding.eu
ST42 ST41
99DS104 99DS103
ST02A
99DS100
ST40 ST 11
99ds402 99ds403
906
IP40
INFRARED MOTION SENSORS
Catalogue number Type Detection Rated load
range
Detection
distance
Colour body Installation
height Length
(mm) Diameter 1 Diameter 2 Packing/Box
(mm)
(mm)
(pcs)
99DS402 ST40 360° 800W (110-130V/AC); 1200W (220-240V/AC) max. 6m
99DS403 ST11 180° white - - -
-
1/100
500W (110-130V/AC) 800W (220-240V/AC) max. 12m white - - -
-
1/50
99DS100 ST02A 160° ESL - 100W, IL - 500W
max. 9m
99DS104 ST42 360° ESL - 300W, IL - 1200W
max.6m
white 1 - 1.8m 80 48.5
24.7
1/100
white 2.2 - 4m 75,6 76
100
1/50
99DS103 ST41 360° ESL - 300W, IL - 1200W
max.6m
white 2.2 - 4m 75,6 61,5
76
1/50
Time-Delay: 10sec ± 3sec to 7min ± 2min (adjustable) | Ambient light: <3 - 2000lux (adjustable) | Detection motion speed: 0.6 - 1.5m/s
50/60
Hz
3+0
standard
+extended
3
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
