LAMPS AND COMPONENTS
www.elmarkholding.eu
ACCESSORIES
Pendant
192165
IP20
LAMP HOLDERS
Catalogue number Type Lamp Material Length
(mm) Diameter 1 Diameter 2 Width
(mm)
(mm)
(mm) d
(mm) r
(mm) Packing/Box
(pcs)
192165 Lamp holder pendant E 27 bakelite 60 38 - - 1/240
3+0
3
-
YEAR TOTAL
WARRANTY
standard
+extended
-
CABLE CONNECTOR IP68
31072
905
TERMINAL BOX IP44
31071
TERMINAL BOX IP65
IP44
IP65
31070
IP68
WATERPROOF TERMINAL CONNECTORS
Catalogue number Type Material Voltage (V) Rated current (A) Wiring Capacity
(mm 2 ) Packing/Box
(pcs)
31071 Terminal box IP44 Polycarbonate 450 6 0.5-4.0 1/500
31070 Terminal box IP65 Polypropylene 450 10 0.5-2.5 1/500
31072 Cable connector IP68 Anti UV nylon 250 ≤30A 0.5-2.5 1/500
3+0
standard
+extended
3
YEAR TOTAL
WARRANTY
