ELMARK Lighting 2019 Lighting_2019 | Page 400

OUTDOOR
FLOODLIGHTS
www.elmarkholding.eu
VEGA SLIM WITH SENSOR
98VEGA10SENSLIM
98VEGA20SENSLIM
98VEGA30SENSLIM
98VEGA50SENSLIM
800
98VEGA10SLIM
98VEGA20SLIM
98VEGA30SLIM
98VEGA50SLIM
98VEGA100SLIM
VEGA SLIM
IP65
VEGA SLIM / VEGA SLIM WITH SENSOR
Catalogue number Watt
(W) Whole fixture lumens
(lm) Colour temp.
(K) Colour body Length
(mm) Width
(mm) Height
(mm) Packing/Box
(pcs)
98VEGA10SLIM 10 900 5500 black 102 24 83 1/40
98VEGA20SLIM 20 1800 5500 black 131 26 117 1/40
98VEGA30SLIM 30 2700 5500 black 215 30 185 1/20
98VEGA50SLIM 50 4500 5500 black 230 30 195 1/20
98VEGA100SLIM 100 9000 5500 black 327 42 265 1/10
98VEGA10SENSLIM 10 900 5500 black 102 50 153 1/50
98VEGA20SENSLIM 20 1800 5500 black 134 34 98 1/30
98VEGA30SENSLIM 30 2700 5500 black 215 30 185 1/20
98VEGA50SENSLIM 50 4500 5500 black 230 30 195 1/10
Energy class
Body: Plastic+Aluminium | LED driver: linear | Light source: SANAN | Input voltage: 220V-240V AC | Cable length: 300 mm | Ambient Temperature: -30°C÷ +65°C
Sensor: | Detection Range:110° | Detection Distance: MAX 8m(adjustable) | Ambient Light: 2-1000 lux (adjustable) | Detection Motion Speed: 0.6-1.5m/s;
Material: PC
Material: Polypropylene 94-V2 grade
Rated operational voltage:AC250V
Voltage: 450V
Sunscreen Rating:Sun Protection(UV)
Rated operational Ampere(A):≤30A
Rated current: 6A
Voltage: 450V
Material: flame retardant/Anti UV nylon(PA66)
Wiring Capacity: 0.5-4.0mm2
Rated current: 10A
Crimping terminals:Nickle-plated brass
Terminal Blocks: 3p screw type
Withstand voltage(normal temperature):3KV
Cat. Number: 31071
Metal Part:Plated Brass/Steel Spring
Operating remperature range: -40°C~+105°C
Wiring Capacity: 0.5-2.5mm2
Wiring Capacity: 0.5-2.5mm2
Terminal box IP44
50/60
Hz
Terminal box IP65
SMD
Ra>70 2
Cat. Number: 31070
Cable connector IP68
3+2
standard
+extended
5
Cat. Number: 31072
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
