ELMARK Lighting 2019 Lighting_2019 | Seite 401

OUTDOOR
www.elmarkholding.eu
FLOODLIGHTS
VEGA SLIM WITH SENSOR
IP65
VEGA SLIM / VEGA SLIM WITH SENSOR
Catalogue number Watt
(W) Whole fixture lumens
(lm) Colour temp.
(K) Colour body Length
(mm) Width
(mm) Height
(mm) Packing/Box
(pcs)
98VEGA10SLIM/WH 10 900 4000 white 111 25 100 1/40
98VEGA20SLIM/WH 20 1800 4000 white 131 26 117 1/40
98VEGA30SLIM/WH 30 2700 4000 white 215 32 185 1/20
98VEGA50SLIM/WH 50 4500 4000 white 230 30 195 1/20
98VEGA100SLIM/WH 100 9000 4000 white 327 42 265 1/10
98VEGA20SENSLIM/WH 20 1800 4000 white 131 26 117 1/30
98VEGA30SENSLIM/WH 30 2700 4000 white 215 30 185 1/20
98VEGA50SENSLIM/WH 50 4500 4000 white 230 32 195 1/10
Energy class
Body: Plastic+Aluminium | LED driver: linear | Light source: SANAN | Input voltage: 220V-240V AC | Cable length: 300 mm | Ambient Temperature: -30°C÷ +65°C
Sensor: | Detection Range:110° | Detection Distance: MAX 8m(adjustable) | Ambient Light: 2-1000 lux (adjustable) | Detection Motion Speed: 0.6-1.5m/s;
Material: PC
Material: Polypropylene 94-V2 grade
Rated operational voltage:AC250V
Voltage: 450V
Sunscreen Rating:Sun Protection(UV)
Rated operational Ampere(A):≤30A
Rated current: 6A
Voltage: 450V
Material: flame retardant/Anti UV nylon(PA66)
Wiring Capacity: 0.5-4.0mm2
Rated current: 10A
Crimping terminals:Nickle-plated brass
Terminal Blocks: 3p screw type
Withstand voltage(normal temperature):3KV
Cat. Number: 31071
Metal Part:Plated Brass/Steel Spring
Operating remperature range: -40°C~+105°C
Wiring Capacity: 0.5-2.5mm2
Wiring Capacity: 0.5-2.5mm2
Terminal box IP44
50/60
Hz
Terminal box IP65
SMD
Ra>70 2
Cat. Number: 31070
Cable connector IP68
3+2
standard
+extended
5
Cat. Number: 31072
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
801
VEGA SLIM
98VEGA10SLIM/WH
98VEGA20SLIM/WH
98VEGA30SLIM/WH
98VEGA50SLIM/WH
98VEGA100SLIM/WH
98VEGA20SENSLIM/WH
98VEGA30SENSLIM/WH
98VEGA50SENSLIM/WH
