OUTDOOR
FLOODLIGHTS
www.elmarkholding.eu
HELIOS SMD
Catalogue number Model Watt
(W) Whole fixture
lumens (lm) Colour temp.
(K) Colour body Length
(mm) Width
(mm) Height
(mm) Packing/Box
(pcs)
98HELIOS10/WH HELIOS10 10 800 4000 white 105 25 85 1/50
98HELIOS20/WH HELIOS20 20 1600 4000 white 128 25 88 1/50
98HELIOS30/WH HELIOS30 30 2400 4000 white 153 25 111 1/30
98HELIOS50/WH HELIOS50 50 4000 4000 white 205 30 160 1/20
98HELIOS100/WH HELIOS100 100 8000 4000 white 300 30 205 1/10
Energy class
Body: Aluminium casting | LED driver: mounted in the body | Light source: Epistar SMD2835 | Input voltage: 176 - 264V | Ambient Temperature: -20°C÷ +55°C
Material: PC
Material: Polypropylene 94-V2 grade
Rated operational voltage:AC250V
Voltage: 450V
Sunscreen Rating:Sun Protection(UV)
Rated operational Ampere(A):≤30A
Rated current: 6A
Voltage: 450V
Material: flame retardant/Anti UV nylon(PA66)
Wiring Capacity:
Rated current: 10A
Crimping terminals:Nickle-plated brass
0.5-4.0mm2
Terminal Blocks: 3p screw type
Withstand voltage(normal temperature):3KV
Metal Part:Plated Brass/Steel Spring
Operating remperature range: -40°C~+105°C
Cat. Number:
Wiring Capacity: 0.5-2.5mm2
Wiring Capacity: 0.5-2.5mm2
31071
Side View
50/60
Hz
Terminal box IP44
120
Ra>70
Terminal box IP65
Cat. Number: 31070
2+0
standard
+extended
2
Cable connector IP68
Cat. Number: 31072
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
799
IP65
