INDOOR
www.elmarkholding.eu
LED PANELS
LED PANEL SQUARE
99LED968CW
99LED968
99LED968WW
LED PANEL SQUARE
99LED967CW
99LED967
99LED967WW
LED PANEL SQUARE OM
99LED969CW
99LED969
99LED969WW
IP40
Catalogue number Watt
(W) Whole fixture lumens Colour temp.
(lm)
(K) Colour body Length
(mm) Width
(mm) Height
(mm) Length1
(mm) Width1
(mm) Packing/Box
(pcs)
99LED967CW 12 890 6300-6500 white 175 175 13 155 155 1/20
99LED967 12 890 4000-4300 white 175 175 13 155 155 1/20
99LED967WW 12 890 2700-3000 white 175 175 13 155 155 1/20
99LED968CW 18 1420 6300-6500 white 225 225 13 205 205 1/20
99LED968 18 1420 4000-4300 white 225 225 13 205 205 1/20
99LED968WW 18 1420 2700-3000 white 225 225 13 205 205 1/20
99LED969CW 18 1420 6300-6500 white 220 220 32 205 205 1/20
99LED969 18 1420 4000-4300 white 220 220 32 205 205 1/20
99LED969WW 18 1420 2700-3000 white 220 220 32 205 205 1/20
Body: aluminium | Light source: Epistar SMD | Starting time: <0.5s | Power factor: λ>0.8
OM - surface mounted luminaire
50/60
Hz
SMD
120
Ra>80
>20000
3
40
3+2
standard
+extended
5
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
Energy class
625
LED PANEL SQUARE
