ELMARK Lighting 2019 Lighting_2019 | Page 224

INDOOR
LED PANELS
www.elmarkholding.eu
LED PANEL STELLAR SQUARE
99XLED637
99XLED636
99XLED636CW
LED PANEL STELLAR SQUARE
99XLED635
99XLED634
99XLED634CW 99XLED633
99XLED632
99XLED632CW
LED PANEL STELLAR SQUARE
LED PANEL STELLAR SQUARE OM
99XLED969
99XLED970
IP40
LED PANELS STELLAR SQUARE
624
Catalogue number Watt
(W) Whole fixture lumens Colour temp.
(lm)
(K) Colour body Length
(mm) Width
(mm) Height
(mm) Length1
(mm) Width1
(mm) Packing/Box Energy class
(pcs)
99XLED633 12 840 2700 white 174 174 21 164 164 1/24
99XLED632 12 840 4000 white 174 174 21 164 164 1/24
99XLED632CW 12 840 6500 white 174 174 21 164 164 1/24
99XLED635 18 1350 2700 white 225 225 21 205 205 1/20
99XLED634 18 1350 4000 white 225 225 21 205 205 1/20
99XLED634CW 18 1350 6500 white 225 225 21 205 205 1/20
99XLED637 24 1800 2700 white 300 300 21 280 280 1/20
99XLED636 24 1800 4000 white 300 300 21 280 280 1/20
99XLED636CW 24 1800 6500 white 300 300 21 280 280 1/20
99XLED969 18 1350 4000 white 220 220 32 - - 1/20
99XLED970 24 1800 4000 white 300 300 32 - - 1/20
Body: aluminium | Light source: SMD 2835 | Starting time: <0.5s | Power factor: 0.55 | Recessed mounted luminaire
50/60
Hz
SMD
120
Ra>80
>10000
40
2+0
standard
+extended
2
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
