ELMARK Lighting 2019 Lighting_2019 | страница 226

INDOOR
LED PANELS
www.elmarkholding.eu
LED PANEL SQUARE
99LED635T
99LED634T
LED PANEL SQUARE
99LED633T
99LED633
LED PANEL SQUARE OM
99LED637T
99LED636T
626
IP40
LED PANEL SQUARE
Catalogue number Watt
(W) Whole fixture lumens
(lm) Colour temp.
(K) Colour body Length
(mm) Width
(mm) Height
(mm) Length1
(mm) Width1
(mm) Packing/Box
(pcs)
99LED633T 9 720 2700-3000 white 148 148 21 130 130 1/40
99LED633 12 960 2700-3000 white 145 145 21 130 130 1/40
99LED635T 18 1440 2700-3000 white 218 218 21 200 200 1/20
99LED634T 18 1440 4000-4300 white 218 218 21 200 200 1/20
99LED637T 18 1440 2700-3000 white 225 - 21 - - 1/24
99LED636T 18 1440 4000-4300 white 225 - 21 - - 1/24
Body: aluminium | Light source: Epistar SMD | Starting time: <0.5s | Power factor: λ>0.8
OM - surface mounted luminaire
50/60
Hz
SMD
120
Ra>80
>20000
3
40
3+2
standard
+extended
5
YEAR TOTAL
WARRANTY
Energy class
