INDOOR
LED PANELS
www.elmarkholding.eu
LED PANEL ROUND IP44
99LED609IP44
99LED609IP44CW
LED PANEL ROUND IP44
99LED611IP44
99LED611IP44CW
LED PANEL ROUND IP44
99LED617IP44
99LED617IP44CW
616
IP44
LED PANEL ROUND IP44
Catalogue number Watt
(W) Whole fixture lumens Colour temp.
(lm)
(K) Colour body Diameter
(mm) Height
(mm) Packing/Box
(pcs)
99LED609IP44 5 400 4000 white 90 21 40
99LED609IP44CW 5 400 6500 white 90 21 40
99LED611IP44 12 960 4000 white 175 21 20
99LED611IP44CW 12 960 6500 white 175 21 20
99LED617IP44 18 1440 4000 white 225 21 20
99LED617IP44CW 18 1440 6500 white 225 21 20
Body: aluminium | Light source: SMD 2835 | Recessed mounted luminaire | Beam angle: 120°| Driver: Isolated
Easy installation due to handy clips | Recessed mounted luminaire.
50/60
Hz
SMD
120
Ra>80
>20000
3
3+2
standard
+extended
5
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
Energy class
