ELMARK Lighting 2019 Lighting_2019 | Page 215

INDOOR
www.elmarkholding.eu
LED PANELS
LED PANEL ECO
99LED962CW
99LED962
99LED962WW
99LED963CW
99LED963
99LED963WW
99LED964CW
99LED964
99LED964WWb
LED PANEL ECO
LED PANEL ROUND ECO SERIES
Catalogue number Dimmable Watt
(W) Whole fixture lumens Colour temp.
(lm)
(K) Colour body Diameter
(mm) Height
(mm) Diameter1
(mm) Packing/Box
(pcs)
99LED960CW - 6 510 6000-6400 white 100 25 80 1/100
99LED960 - 6 510 4000-4300 white 100 25 80 1/100
99LED960WW - 6 510 2700-3000 white 100 25 80 1/100
99LED961CW - 12 1020 6000-6400 white 145 25 125 1/60
99LED961 - 12 1020 4000-4300 white 145 25 125 1/60
99LED961WW - 12 1020 2700-3000 white 145 25 125 1/60
99LED962CW - 18 1530 6000-6400 white 170 25 150 1/60
99LED962 - 18 1530 4000-4300 white 170 25 150 1/60
99LED962WW - 18 1530 2700-3000 white 170 25 150 1/60
99LED963CW - 24 2040 6000-6400 white 195 25 175 1/30
99LED963 - 24 2040 4000-4300 white 195 25 175 1/30
99LED963WW - 24 2040 2700-3000 white 195 25 175 1/30
99LED964CW - 28 2500 6000-6400 white 220 25 200 1/20
99LED964 - 28 2500 4000-4300 white 220 25 200 1/20
99LED964WW - 28 2500 2700-3000 white 220 25 200 1/20
Body: PC | Reflector: policarbonate (pc) | Light source: Epistar SMD2835 | Starting time: <0.5s | Power factor: λ>0.8
Easy installation due to handy clips | Recessed mounted luminaire.
50/60
Hz
SMD
Ra>80
>20000
3
40
3+2
standard
+extended
5
YEAR TOTAL
WARRANTY
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
Energy class
615
IP40
99LED960CW
99LED960
99LED960WW
99LED961CW
99LED961
99LED961WW
