INDOOR
www.elmarkholding.eu
LED PANELS
WATERPROOF LED PANEL ROUND
99LED609IP65
99LED609IP65CW 99LED611IP65
99LED611IP65CW
WATERPROOF LED PANEL ROUND
WATERPROOF LED PANEL ROUND
99LED617IP65
99LED617IP65CW
617
WATERPROOF LED PANEL ROUND
Catalogue number Watt
(W) Whole fixture lumens Colour temp.
(lm)
(K) Colour body Diameter
(mm) Height
(mm) Packing/Box
(pcs)
99LED609IP65 5 400 4000-4300 white 90 27 1/40
99LED609IP65CW 5 400 6300-6500 white 90 27 1/40
99LED611IP65 10 800 4000-4300 white 150 27 1/40
99LED611IP65CW 10 800 6300-6500 white 150 27 1/40
99LED617IP65 18 1440 4000-4300 white 225 27 1/20
99LED617IP65CW 18 1440 6300-6500 white 225 27 1/20
Body: policarbonate (pc) | Reflector: policarbonate (pc) | Light source: Epistar | Starting time: <0.5s | Power factor: λ>0.8
Easy installation due to handy clips | Recessed mounted luminaire.
50/60
Hz
SMD
120
Ra>80
>20000
3
3+2
standard
+extended
5
In case of insufficient quantity in stock of any item listed on this page, the delivery time after order confirmation will be 90 days.
YEAR TOTAL
WARRANTY
Energy class
IP65
