Easikit Catalogue from Coveya Coveya Easikit catalogue | Page 31
Price code
Snub
Standard
Self Adjusting Belt Scraper
This is the perfect solution for keeping your belt
clean when access to the drive drum is difficult
and you want peace of mind that your belt will be
kept clean without the need to manually adjust the
scraper blade. Ideal for conveyors in locations where
low maintenance is required.
Price code
Easikit 450 440 n/a Easikit 450 450SA
Easikit 600 640
940
1240
1542 642
942
1242 Easikit 600 600SA
900SA
1200SA
1500SA
Easikit 900
Easikit 1200
Easikit 1500
n/a
Secondary Belt Scraper
Assist the primary scraper in helping to prevent
material carry-back on the return belt. Suitable
for plain belt and clipped or vulcanised joints, the
secondary scraper is mounted behind the primary
scraper and shares the same bracket as the Primary
Scraper mounted onto the drive drum bearing. The
scraper has a manually adjustable polyurethane blade
which provides a good back up when fitted with the
primary scraper, especially when handling sticky
material, i.e. sewage cake.
Price code
Snub
Standard
Easikit 450 441 n/a
Easikit 600 641
941
1241
1543 643
943
1243
Easikit 900
Easikit 1200
Easikit 1500
n/a
Easikit 900
Easikit 1200
Easikit 1500
Finger Belt Scraper
These are the ultimate option for keeping your belt
clean. The heavy duty finger scrapers are suitable for
cleaning chevron belt or for plain belt if required. The
scrapers come supplied complete with a heavy duty
mounting frame. There are 2 types of scraper available.
A. FLAT BELT SCRAPER 5 finger blades with carbide
inserts for use on all materials
B. CHEVRON BELT SCRAPER 7 finger blade with
stainless steel inserts. For chevron belts transporting
glass, clay and other hard to remove materials
Price code
A B
Easikit 450 444A 444B
Easikit 600 644A
944A
1244A
1544A 644B
944B
1244B
1544B
Easikit 900
Easikit 1200
Easikit 1500
Primary Belt Scraper
A cost effective way to help prevent material carry-
back on the return belt when conveying viscous
material. Suitable for plain belt and clipped or
vulcanised joints, the primary scraper has a manually
adjustable polyurethane blade and is mounted on the
drive drum bearing for easy fitting.
31
