Easikit Catalogue from Coveya Coveya Easikit catalogue | Page 30

110v
110v
336
415v
337
415v
Motor mounting and wiring
Motor and gearbox pre mounted on shaft and wired to a plug
to work in conjunction with the starter box and leads.
Up to 10m
630
Over 10m
631
A legal requirement for conveyors over 5m in length and
accessible.
Price code
1.5kW 110V 330
2.2kW 110V 331
1.5kW 415V 332
3kW 415V 333
Starter Box
Remote starter box that can be placed within easy access
of working area by a 6m lead to the drive motor on the head
unit once the conveyor has been installed. This box provides
a thermal overload to protect the motor and is supplied with
a 6m Emergency Stop lead. Minimum transformer size for
running one conveyor is 5kVA. To avoid voltage drop, do not
have long leads.
632
1.5kW
633
3kW
Price Code
334
Lead Set
Set of two heavy duty bespoke leads required for use with
Starter Box. These connect between power supply, control
panel and motor. Ensures that power supply is via the Starter
Box providing necessary protection for the motor.
634
4kW
338
Transformers
5kVA transformer for 240V to 110V supply with a
continuously rated output of 3kVA 32A to run a 1.5kW –
2.2kW 110V motor. One transformer per conveyor is needed.
Price code
WARNING Long leads = voltage drop
Motor Starter
Direct-on-line starter in durable enclosure incorporating
thermal overload for motor protection. Sealed to IP65.
Supplied Loose.
635
637
Price Code
Emergency Stop Station
Emergency stop st
