MODULAR CONVEYOR COMBINATIONS CONVEYOR SECTIONS Price Code 1201 Head drive unit Length Combination of conveyor sections MODULAR CONVEYOR COMBINATIONS Metres Feet Price Code 1202 Base tension unit 2.86m 4.06m 5.26m 6.46m 7.66m 8.86m 10.06m 11.26m 12.46m 13.66m 14.86m (9’) (13’) (17’) (21’) (25’) (29’) (33’) (37’) (41’) (45’) (49’) H + T UNITS H + T + 1.2m section H + T + 2.4m section H + T + 1.2 + 2.4m section H + T + 2 x 2.4m section H + T + 1.2m + 2 x 2.4m sections H + T + 3 x 2.4m sections H + T + 1.2m + 3 x 2.4m sections H + T + 4 x 2.4m sections H + T + 1.2m + 4 x 2.4m sections H + T + 5 x 2.4m sections Belt length Weight incl. plain belt & motor 6.1m 8.5m 10.9m 13.3m 15.7m 18.1m 20.5m 22.9m 25.3m 27.7m 30.1m 339kg 418kg 488kg 566kg 637kg 715kg 864kg 942kg 1091kg 1169kg 1318kg 32.6m 35m 37.4m 39.8m 42.2m 44.6m 47m 49.4m 51.8m 1439kg 1588kg 1666kg 1815kg 1893kg 2042kg 2120kg 2269kg 2347kg Snub drum unit and 4kW 415v motor for lengths of 16.06m and over Price Code 1203 1.2m intermediate section Price Code 1204 2.4m intermediate section 16.06m 17.26m 18.46m 19.66m 20.86m 22.06m 23.26m 24.46m 25.66m ( 53’) (57’) (61’) (65’) (69’) (73’) (77’) (81’) (85’) H + T + 1.2m + 5 x 2.4m sections H + T + 6 x 2.4m sections H + T + 1.2m + 6 x 2.4m sections H + T + 7 x 2.4m sections H + T + 1.2m + 7 x 2.4m sections H + T + 8 x 2.4m sections H + T + 1.2m + 8 x 2.4m sections H + T + 9 x 2.4m sections H + T + 1.2m + 9 x 2.4m sections LONGER COMBINATIONS AVAILABLE For vulcanised belt joints allow 1.5m extra belt. Maximum length of conveyor depends on application. CONVEYOR DRIVES Motor Price Code 1205 Snub drive unit Recycling Price Code 1208 Recycling Medium steel hopper Standard Drive Snub Drive 4 Belt Speed Belt Pull Code Belt Speed Belt Pull Code 1.5kW 415V 3 phase motor 0.3m/sec 3749N 610 - - - 3kW 415V 3 phase motor 0.7m/sec 3602N 611 - - - 3kW 415V 3 phase motor 0.9m/sec 2764N 612 - - - 2.2kW 110V single phase motor 0.7m/sec 2639N 613 - - - 2.2kW 110V single phase motor 0.9m/sec 2031N 614 - - - 2.2kW 415V 3 phase motor - - - 0.3m/sec 7880N 618 4kW 415V 3 phase motor - - - 0.7m/sec 4795N 617 4kW 415V 3 phase motor - - - 0.9m/sec 3883N 615 4kW 415V 3 phase motor - - - 1.2m/sec 2946N 616 17
