System 500 514
Nut- und Formfräsen Fräsplatte Sicherungsringe
DIN 471 / 472
groove milling
by circular interpolation milling insert
for circlips DIN 471 / 472
R
γ
λ
α
IK = 13
r
s
r
dimensions in mm
Abmessungen in mm righthand (514.): as shown
lefthand (L514.): mirror image
Rechts (514.): wie gezeichnet
Links (L514.): spiegelbildlich
carbide grade
r
3°
3°
60°
388
1.3
1.6
1.85
2.15
2.65
3.15
4.15
5.15
5.4
5.4
5.4
5.4
5.4
5.4
5.4
5.4
1.41
1.71
1.96
2.26
2.76
3.26
4.26
5.26
0.1
0.15
0.15
0.15
0.15
0.15
0.15
0.15
3°
3°
3°
3°
3°
3°
3°
3°
Typ 500
Typ 510
Typ 581
AL41F
Weitere HM Sorten können Sie in der Sorten-
übersicht im Kapitel »Technische Hinweise« und
der Preisliste finden. More carbide grades you can find in the grades
summary in the chapter »technical instructions«
and in the price list.
Bestellbeispiel für Sorte AL41F:
Rechts: 514.0130.00-D/AL41F
Links: L514.0130.00-D/AL41F (auf Anfrage) order-example grade AL41F:
righth.: 514.0130.00-D/AL41F
lefth.: L514.0130.00-D/AL41F (on demand)
514.0130.00-D
514.0160.00-D
514.0185.00-D
514.0215.00-D
514.0265.00-D
514.0315.00-D
514.0415.00-D
514.0515.00-D
