MINICUT
Übersicht
Bohrungsbearbeitung
summary
Schneidplatten
Ausdrehen und
Kopieren
Maße
dimensions
Seite
page
Typ Ausdrehen und
Kopieren innen von gehärteten Teilen mit CBN boring and copying internal
of hardened parts with CBN D min. 7.8 - 15.5 ... 133
Typ Ausdrehen und
Kopieren innen allgemein boring and copying internal,
general D min. 7.8 - 15.5 ... 134
Typ Ausdrehen und
Kopieren innen allgemein,
Innenfreistiche DIN 509 boring and copying internal,
undercuts DIN 509 D min. 7.8 - 20 ... 135
Typ Ausdrehen und
Kopieren innen Ausdrehen mit spezieller Spantreppe boring with special chipformer D min. 8 / 9 / 11
t max. 0.5 ... 136
Typ Ausdrehen und
Kopieren innen Rückwärtsdrehen innen boring by backward motion internal D min. 7.8 - 13.8 ... 137
Typ Ausdrehen und
Kopieren innen Fasen und Ausdrehen innen chamfering and profiling internal D min. 8 - 14 ...138
Maße
dimensions Seite
page
Schneidplatten
Gewindedrehen
108
inserts
boring and copying
inserts
threading
Typ Gewindedrehen metrisches ISO-Gewinde,
innen Teilprofil metric ISO-thread,
internal partial profile D min. 8 / 9 ... 139
Typ Gewindedrehen metrisches ISO-Gewinde,
innen Teilprofil metric ISO-thread,
internal partial profile D min. 11 / 14
/ 16 ... 140
Typ Gewindedrehen metrisches ISO-Gewinde,
innen Vollprofil metric ISO-thread,
internal full profile D min. 9 / 11 ... 141
Typ Gewindedrehen metrisches ISO-Gewinde,
innen Vollprofil metric ISO-thread,
internal full profile D min. 14 / 16 ... 142
Typ Gewindedrehen NPT Vollprofil type threading, NPT full profile D min. 8 ... 143
Typ Gewindedrehen für Whitworth-Gewinde,
innen Vollprofil Whitworth thread,
internal full profile D min. 11 / 14
/ 16 ... 144
Typ Gewindedrehen Trapezgewinde,
innen Teilprofil trapezoidal thread,
internal partial profile D min. 9 / 10 / 11 ... 145
Typ Gewindedrehen Trapezgewinde,
innen Teilprofil trapezoidal thread,
internal partial profile D min. 14 / 16 ... 146
grooving, boring and profiling
