MINICUT
Übersicht
Bohrungsbearbeitung
summary
Schneidplatten
Stechdrehen
inserts
grooving
Maße
dimensions Seite
page
Typ Stechdrehen innen für Sicherungsringe DIN 471/472
und Stechdrehen allgemein type grooving internal,
for circlips DIN 471/472 and grooving D min. 8 ...121
Typ Stechdrehen innen für Sicherungsringe DIN 471/472
und Stechdrehen allgemein type grooving internal,
for circlips DIN 471/472 and grooving D min. 9 ...122
Typ Stechdrehen innen für Sicherungsringe DIN 471/472
und Stechdrehen allgemein type grooving internal,
for circlips DIN 471/472 and grooving D min. 11 ...123
Typ Stechdrehen innen für Sicherungsringe DIN 471/472
und Stechdrehen allgemein type grooving internal,
for circlips DIN 471/472 and grooving D min. 14 ...124
Typ Stechdrehen innen für Sicherungsringe DIN 471/472
und Stechdrehen allgemein type grooving internal,
for circlips DIN 471/472 and grooving D min. 16 ...125
Typ Stechdrehen innen Stechdrehen allgemein type grooving internal,
general use D min. 18 / 20
t max. = 6 / 8 ...126
Typ Stechdrehen innen Stechdrehen allgemein,
große Einstechtiefe type grooving internal, general use,
maximum depth of groove D min. 16 / 17
t max. = 5.5 / 6.5 ...127
Typ NC Feindrehen NC Feindrehen, innen type NC-profiling, internal D min. 8 - 16 ...128
Typ NC Feindrehen NC Feindrehen, innen,
große Einstechtiefe type NC-profiling, internal,
maximum depth of groove D min. 16 / 17
t max. = 5.5 / 6.5 ...129
Typ Stechdrehen innen Vollradius type grooving internal,
full radius D min. 8 / 9 / 11
t max. 1 / 1.6 /2.3 ...130
Typ Stechdrehen innen Vollradius type grooving internal,
full radius D min. 14 / 16
t max. 4.0 / 4.3 ...131
Typ Stechdrehen innen Vorstechen und Fasen type grooving internal,
pregrooving and chamfering D min. 8 - 16 ...132
grooving, boring and profiling
107
