CMA 11605 – Lever Actuator
• Molded design for recessed mounting with larger lever for ease of actuation
• Optional cable control assembly locations for flexible routing in vertical or horizontal installations or
two cable controls at the same time.
• Pocket mounting holes and return spring are standard
• Easily assembled to CMA standard cable controls
5"
➤
➤
35/8"
Position "A" 2:1 Mechanical advantage
➤
➤
➤
.840" (21.3 mm) travel
➤
➤
3"
1"
➤
Position "B" 1.7:1 Mechanical advantage
2.22
➤
➤
➤
➤
.28
31/32"
➤
➤
1.52
➤ ➤
➤
Material: ABS/polycarbonate
211/16"
227/32"
Color: Black
➤
POSITION “B”
➤
➤
1.300" (33.0 mm) travel
POSITION “A”
“A“
Use Molded End No. 3
CMA 11604 – Push Button Actuator Round Button/Bezel
• Molded design with large push button for finger or palm actuation
• Adjustable trim ring accommodates mounting surface thickness
• Rear or front surface 4-hole mounting plate
• Integral return spring (optional)
• Supplied assembled to CMA standard cable controls
31/4"
➤
➤
.949 TYP.
.480" (12.4 mm) travel
.949 TYP.
➤
➤
➤
➤
➤
Material: Engineering grade thermo-plastics
2.52
➤
Color: Black
21/2"
➤
➤
➤
.17 DIA.
TYP.
11/2" DIA.
➤➤ ➤
➤
2.08
DIA.
➤
➤
➤
➤
➤
25/8"
NOTE: For locking gas spring applications, when used with CMA 11602, 11708, or 12030 –
specify a gas spring with quick release valve (1mm travel).
➤
➤
2"
➤
➤
➤
.59 MIN.
.87 MAX.
.65
.744
➤
➤
➤
.75
WITH BUTTON
DEPRESSED
MOUNTING
SURFACE
Use Molded End No. 3
