Remote Actuation Systems
ACTUATORS
CMA 11603 – Lever Actuator
• Compact molded housing with vertical lever for fingertip actuation
• Recessed mounting with two bezel holes
• Easily assembled to CMA standard cable controls. Cable fitting permanently snaps into lever handle.
2:1 Mechanical advantage
9/16" (14.3 mm) travel
Material: ABS/glass filled nylon
Color: Black
2 21/32"
2.060 .020
C 1 23 /32"
L
NOTE: For locking gas spring applications, when used with CMA 11602, 11708, or 12030 –
specify a gas spring with quick release valve (1mm travel).
1/2"
1 9/32"
1 17/32"
1 1 /4"
ìA “
Use Molded End No. 1
CMA 11764 – Mini Lever Actuator
• Molded compact design for recessed mounting
• Contoured handle for easy two-finger operation
• Optional cable control assembly locations for flexible routing in vertical or horizontal applications
• Integral return spring
• Bezel or pocket mounting holes
➤
33/4"
3.190
• Easily assembled to CMA standard cable controls
➤
➤
➤
➤
➤
➤
115/16"
➤
➤
31/32"
➤
.140 DIA.
FOR #6 FLAT/OVAL
HEAD SCREW*
➤
➤
1.390
1.450
➤
➤
➤
1/2
➤
➤
2.850
* AVAILABLE W/O
BEZEL MOUNTING
HOLES FOR SIDE
HOLE MOUNTING
REQUIREMENTS.
POSITION “A”
TRAVEL .750
POSITION “B”
TRAVEL .750
Position "A" 3.5:1 Mechanical advantage
.750" (19.0 mm) travel
Position “B” 4:1 Mechanical advantage
.750” (19.0 mm) travel
Material: ABS/polycarbonate
Color: Black
“A“
Use Molded End No. 4
