WARNING
Remove Left-Hand Door
Excessive Weight Hazard
Use two or more people to lift the refrigerator door.
IMPORTANT: The wiring for UI run through left-hand door hinge,
so they must be disconnected before removing the door.
1. Using a Phillips screwdriver, remove cover from top hinge.
Failure to do so can result in back or other injury.
A
Remove Refrigerator Doors
B
WARNING
Electrical Shock Hazard
Disconnect power before removing doors.
A. Top hinge cover screw
B. Top hinge cover
Failure to do so can result in death or electrical shock.
Remove Right-Hand Door
2. Disconnect two wiring plugs located on top of the door hinge.
1. Unplug refrigerator or disconnect power.
2. Keep refrigerator doors closed until you are ready to lift them
free from the cabinet.
NOTE: Provide additional support for refrigerator door while
the hinges are being removed. Do not depend on door gasket
magnets to hold the door in place while you are working.
3. Using a Phillips screwdriver, remove cover from top hinge.
4. Using 5 mm socket wrench, remove four screws from top
hinge and set aside.
■ ■
Grasp each side of wiring plugs. With your left thumb,
press down to release the catch and pull the sections of
the plugs apart.
A
A
B
C
D
A. Top hinge cover screw
B. Top hinge cover
C. 5 mm socket screws
D. Top hinge
5. Lift the refrigerator door from the middle hinge pin. The top
hinge will come away with the door.
12
B
A. Wiring Plug
B. Ground (earth) connector
