Turnspit*
If the appliance is fitted with an electronic lighting device*
(see figure), press the ignition button, marked with the
To operate the rotisserie
(see diagram) proceed as
follows:
1. Place the dripping pan
in position 1.
2. Place the rotisserie
support in position 4 and
insert the spit in the hole
provided on the back
panel of the oven.
, then hold the OVEN control knob and turn it
symbol
in an anticlockwise direction, towards the MAX position,
until the burner is lit. If, after 15 seconds, the burner is
still not alight, release the knob, open the oven door and
wait for at least 1 minute before trying to light it again. If
there is no electricity the burner may be lit using a flame
or a lighter, as described above.
! The oven is fitted with a safety device and it is therefore
necessary to hold the OVEN control knob down for
approximately 6 seconds.
! If the flame is accidentally extinguished, switch off the
burner and wait for at least 1 minute before attempting
to relight the oven.
GB
3. Acitvate the function by pressing the TURNSPIT button.
Oven light
The light may be switched on at any moment by pressing
the OVEN LIGHT button.
Adjusting the temperature
Timer*
To set the desired cooking temperature, turn the OVEN
control knob in an anticlockwise direction. Temperatures
are displayed on the control panel and may vary between
MIN (150°C) and MAX (250°C). Once the set temperature
has been reached, the oven will keep it constant by using
its thermostat.
Grill
To light the grill, bring a flame or gas lighter close to the
burner and press the OVEN control knob while turning
it in a clockwise direction until it reaches the position.
The grill enables the surface of food to be browned evenly
and is particularly suitable for roast dishes, schnitzel
and sausages. Place the rack in position 4 or 5 and the
dripping pan in position 1 to collect fat and prevent the
formation of smoke.
To activate the Timer proceed as follows:
1. Turn the TIMER knob in a clockwise direction for
almost one complete revolution to set the buzzer.
2. Turn the TIMER knob in an anticlockwise direction
to set the desired length of time.
WARNING! The oven is provided with
a stop system to extract the racks and
prevent them from coming out of the
oven.(1)
As shown in the drawing, to extract
them completely, simply lift the racks,
holding them on the front part, and
pull (2).
! The grill is fitted with a safety device and it is therefore
necessary to hold the OVEN control knob down for
approximately 6 seconds.
! If the flame is accidentally extinguished, switch off the
burner and wait for at least 1 minute before attempting
to relight the grill.
D
! When using the grill, leave the
oven door ajar, positioning the
deflector D between the door and
the control panel (see fi gure) in
order to prevent the knobs from
overheating.
* Only available in certain models.
15
