Start-up and use
GB
Using the hob Flame adjustment according to levels
Lighting the burners the burner flame intensity can be adjusted with the
knob according to 6 power levels, from maximum
to minimum with 4 intermediate positions:
For each BURNER knob there is a complete ring showing
the strength of the flame for the relevant burner.
To light one of the burners on the hob:
1. Bring a flame or gas lighter close to the burner.
2. Press the BURNER knob and turn it in an anticlockwise
direction so that it is pointing to the maximum flame
setting .
3. Adjust the intensity of the flame to the desired level by
turning the BURNER knob in an anticlockwise direction.
This may be the minimum setting , the maximum setting
or any position in between the two.
If the appliance is fitted with an electronic lighting
device*(D) (see fi gure), press
the ignition button, marked with
, then hold the
the symbol
BURNER knob down and turn
it in an anticlockwise direction,
towards the maximum flame
D
setting, until the burner is lit.The
burner may be extinguished
when the knob is released. If
this occurs, repeat the operation, holding the knob down
for a longer period of time.
X
a click will indicate the change from one level to
another when turning the knob. The system
guarantees a more precise adjustment, allows
to replicate the flame intensity and to identify
easily the preferred level for different cooking
operations.
To identify the type of burner, please refer to the diagrams
contained in the “Burner and nozzle specifications”.
Burner
Cookware Diameter (cm)
Fast (R) 24 - 26
Semi Fast (S) 16 - 20
Auxiliary (A) 10 - 14
Triple Crown (TC) 24 - 26
! On the models supplied with a reducer shelf, remember
that this should be used only for the auxiliary burner when
you use casserole dishes with a diameter under 12 cm.
Using the oven
! If the flame is accidentally extinguished, switch off the
burner and wait for at least 1 minute before attempting
to relight it.
If the appliance is equipped with a flame failure safety
device*(X), press and hold the BURNER knob for
approximately 3-7 seconds to keep the flame alight and
to activate the device.
To switch the burner off, turn the knob until it reaches the
stop position •.
Practical advice on using the burners
For the burners to work in the most efficient way possible
and to save on the amount of gas consumed, it is
recommended that only pans that have a lid and a flat
base are used. They should also be suited to the size of
the burner.
WARNING! The glass lid can break in if it
is heated up. Turn off all the burners and
the electric plates before closing the lid
.
! The first time you use your appliance, heat the empty
oven with its door closed at its maximum temperature
for at least half an hour. Ensure that the room is well
ventilated before switching the oven off and opening the
oven door. The appliance may emit a slightly unpleasant
odour caused by protective substances used during the
manufacturing process burning away.
! Never put objects directly on the bottom of the oven; this
will avoid the enamel coating being damaged. Only use
position 1 in the oven when cooking with the rotisserie
spit.
Lighting the oven
F
To light the oven burner, bring
a flame or gas lighter close to
opening F (see fi gure) and press
the OVEN control knob while
turning it in an anticlockwise
direction until it reaches the MAX
position.
* Only available in certain models.
