maximum flexibility. An AV Stumpfl ISEO was the main control
platform pulling all installation elements into one master control
system. This has the ability to operate and communicate with all
other systems, devices and applications as well as monitoring
devices. ISEO also controls the video mixing and switching and
all playback devices involved. System Solutions provided a multi
channel high definition and standard definition IPTV distribution
system comprising high definition (HD) hardware encoders, DVB
Gateways at the head end to convert live TV to IP for streaming
and HD receivers and display screens to the back of house, VIP
and hospitality suites.

• Amitie Stadium control room

MOSES MABHIDA STADIUM
KWAZULU NATAL
The US$2.6m contract required HD IPTV, digital signage video
distribution system and one large format, high resolution
outdoor LED screen. The control architecture model used was
similar to that implemented at Soccer City, except the new
Christie Spyder X20 was also deployed.
The input configuration comprised four feeds from the AV
Stumpfl Wings Platinum 4 media server; four HD SDI feeds for the
outside broadcast and pitch feeds; and two Blu-ray player inputs.
On the output stage, the Spyder X20 sent an XGA signal over fibre to the Lighthouse big screen and provided two RF Modulator
feeds for the private suites, two HD IPTV Encoders, an operators
monitor and a source multiview.

Cover story
control system was implemented.
The LED display screens were made up of P
