Work
| 222
Dimensions
C
D
E
I
F
K
B
J
A
G
Model
A
B
C
D
E
F
G
J
I
SER 5504
36 1/
32 1/
14
2 2/
8
8
36 1/
32 1/
22
3
5
5
3
2
Dimensional information is in inches.
* Electrical box can easily be relocated to the field to either the front or the back of the cabinet, depending on port direction installer chooses.
Operation diagram
= fresh air to inside
= fresh air from outside
= stale air from inside
= stale air to outside
Specifications
•
•
•
•
•
Model: SER 5504
Total assembled weight: 169 lbs
Cabinet: 20 ga. steel w/powder coat finish
Motors: backward curved blades
Mounting: unit may be suspended by using threaded rod (not supplied) or
•
•
•
placed on a platform
Insulated with 1” aluminum foil-face fiberglass insulation
to prevent condensation and meet the requirements of the UL 94HF
Filters: 4 washable electrostatic filters
Core: 2 cores each 12” x 12” with a 15” depth
Accessories
Eco-TouchTM
Wal
