SER 8504
Commercial Energy Recovery Ventilator
The SER Series lowers demand on air conditioning systems. Air supplied from
outdoors enters through the energy recovery core where it transfers the heat
and moisture the incoming air to the outgoing air that was cooled and dried by
the building’s air conditioner. The air brought into the working area is cooled
and the humidity is reduced for maximum comfort. Reduces the load on an air
conditioner to save on cooling costs. This unit is designed for warmer, humid
climates with longer cooling seasons.
A preset defrost sequence is activated at an outdoor air temperature of 23ºF
and lower. During the defrost sequence, the supply blower shuts down & the
exhaust blower continues to ventilate for a few minutes. The unit then returns
to normal operation, and continues cycle.
Airflow up to 900 cfm @ 0.4” Ps
Push-pull configuration
External low voltage contacts
No defrost
Dual service doors & reversible electrical box
External three position switch (Low/Standby/Medium)
Improved BMS integration
•
•
•
•
•
•
•
Maximum continuous airflow
in.wg
0.4” Ps
0.5” Ps
0.6” Ps
0.7” Ps
0.8” Ps
0.9” Ps
1.0” Ps
1.1” Ps
1.2” Ps
1.3” Ps
1.4” Ps
1.5” Ps
1.6” Ps
Supply air flow (high)
900
860
821
781
741
702
662
622
583
543
503
464
424
Exhaust air flow (high)
900
860
821
781
741
702
662
622
583
543
503
464
424
cfm
Energy performance
Supply temperature
Net Airflow
Sensible recovery efficiency
Latent recovery efficiency
Total recovery efficiency
F
cfm
%
%
%
Heating
35
560
67
39
57
35
420
70
46
62
Cooling
95
560
64
28
42
95
420
67
34
47
O
Specification data
SER 8504
fantech
Voltage /
phase
Rated
power
Max
amps
Average airflow @
0.4” Ps
V/~
Model
W
A
cfm
120
1320
11.0
900
Connection
Defrost
cycle
Side
Auto
Shipping
weight
Item #
lbs
280
List price
USD
44926
4,782.00
