378 5-4. Using the driving support systems
Setting button
Changes settings, such as the automatically display cornering view, the vehicle body color, the SUBARU Parking Assist detection distance.( �P. 401)
Tilt meter Displays the vehicle’ s estimated degree of incline.( �P. 364)
n Under vehicle terrain view( rear side)
lThe screen can be displayed when the shift position is in R.
lWhile the under vehicle terrain view( rear side) is displayed, if the
vehicle speed reaches or exceeds
approximately 3 mph( 5 km / h), the screen automatically returns to the
previous display.
lIn the following situations, the display of the under vehicle terrain
view( rear side) ends and the screen automatically returns to the
most recently used camera screen. In addition, the under vehicle terrain view( rear side) selection switch cannot be operated until the next screen can be displayed.
• When the tires are slipping or spinning
• ABS is activated
• When there is a malfunction in the system
• Rear Cross Traffic Alert, Rear
Camera Detection or Parking Support Brake is activated
• When the back door is open
lIf the outside rear view mirrors are folded while the under vehicle terrain view( rear side) is being displayed, a separate screen is displayed.
lIf the vehicle is driven with the steering wheel turned to a certain steering angle or greater, a part of the screen may disappear. However, this is not a malfunction.
lIn the following situations, the system may not operate normally or
may not be able to switch to the under vehicle terrain view( rear side). In addition, the under vehicle terrain view( rear side)
selection switch cannot be operated until the next screen can be
displayed.
• The road is covered with snow
• When there are shadows due to light sources such as sunlight or
illumination
• When driving on slippery roads or tires are spinning
• Dirt or foreign matter is adhering to the camera lens
• There is water in front of the vehicle( a river, puddle, sea water, etc.)
• Optional equipment has been installed
• When the camera is covered or there is an object in the image capture range
• Tires have been replaced
• When the back door is open
• When the steering wheel is operated at or more than a specified steering angle
• On roads that are not flat, such as slopes
